Product Details | FIRING PIN
1010-00-438-7455 An item used in a firing mechanism of a gun, mine, bomb, fuze, projectile, or the like, which strikes and detonates a sensitive explosive to initiate an explosive train or a propelling charge.21410050018Guns, through 30mm10100026Guns, over 30mm up to 75mm10150024Guns, 75mm through 125mm10200030Guns, over 125mm through 150mm10250030Guns, over 150mm through 200mm10300030Guns, over 200mm through 300mm10350016Guns, over 300mm10550033Launchers, Rocket and Pyrotechnic10950021Miscellaneous Weapons11350043Fuzing and Firing Devices, Nuclear Ordnance13250005Bombs13360048Guided Missile Warheads and Explosive Components13500038Underwater Mines and Components, Inert13770056Cartridge and Propellant Actuated Devices and Components
Part Alternates: 8448327, 98336, 1010-00-438-7455, 00-438-7455, 1010004387455, 004387455
Weapons | Guns, over 30mm up to 75mm
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 10 | 01 DEC 1969 | 00-438-7455 | 22114 ( PIN, FIRING ) |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 1010-00-438-7455
1010-00-439-1773, 1010-00-439-1781, 1010-00-439-1788, 1010-00-439-6249, 1010-00-439-6250
Technical Data | NSN 1010-00-438-7455
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL, MIL-S-5000, COMP E4340 |
| SURFACE TREATMENT | CHROMIUM PLATED |
| METALLIC HARDNESS RATING | 48.0 MINIMUM ROCKWELL C AND 52.0 MAXIMUM ROCKWELL C |
| CASEHARDENING INDICATOR | NOT CASEHARDENED |
| OVERALL LENGTH | 1.757 INCHES MINIMUM AND 1.762 INCHES MAXIMUM |
| STRIKING END DIAMETER | 0.093 INCHES MINIMUM AND 0.095 INCHES MAXIMUM |
| STRIKING END RADIUS | 0.070 INCHES MINIMUM AND 0.085 INCHES MAXIMUM |
| FIRING PIN TYPE | MULTIPLE SHOULDER |
| STRIKING END TYPE | SPHERICAL |
| SPECIAL FEATURES | 63 MICROINCH AA FINISH ON STRIKING END SURFACES |
| III FSC APPLICATION DATA | LAUNCHER,GRENADE,40MM |
| MANUFACTURERS CODE | 19204 |
| DESIGN CONTROL REFERENCE | 8448327 |
Restrictions/Controls & Freight Information | NSN 1010-00-438-7455
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | M | 85 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 685 | unknown |
| Originating Activity Code | BF | U.S. Army Armament and Chemical Acquisition and Logistics Activity Rock Island, IL 61299-6000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1010-00-438-7455
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9H | Navy-owned stocks of consumable material managed by the Army within the Army Armament Materiel Readiness Command Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | B14 | US Army Armament and Chemical Acquisition and Logistics Activity ATTN: AMSTA-AC Rock Island, IL 61299-6000 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
A EA : Each |
