Product Details | AIRCRAFT BEAM
1560-00-765-1101 A long, major, rigid structural member supported at one or both ends. It is designed to carry shear loads and bending moments.
Part Alternates: 274156, 2-74156, 2741591, 2-74159-1, 1560-00-765-1101, 00-765-1101, 1560007651101, 007651101
Aircraft and Airframe Structural Components | Airframe Structural Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 15 | 01 JAN 1962 | 00-765-1101 | 41020 ( BEAM, AIRCRAFT ) |
Drawings & Photos | NSN 1560-00-765-1101
Demand History | NSN 1560-00-765-1101
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1560-00-765-1101 | 2020-10-19 | 42 | DIBBS |
| 1560-00-765-1101 | 2019-04-10 | 44 | DIBBS |
| 1560-00-765-1101 | 2019-03-19 | 4 | DIBBS |
| 1560-00-765-1101 | 2019-03-17 | 35 | DIBBS |
| 1560-00-765-1101 | 2016-03-08 | 1 | DIBBS-RFPs |
| 1560-00-765-1101 | 2015-10-01 | 31 | DIBBS |
| 1560-00-765-1101 | 2015-07-21 | 17 | United States |
| 1560-00-765-1101 | 2014-11-17 | 18 | DIBBS |
| 1560-00-765-1101 | 2014-10-08 | 36 | DIBBS |
| 1560-00-765-1101 | 2013-02-10 | 71 | DIBBS |
| 1560-00-765-1101 | 2011-11-09 | 13 | DIBBS |
| 1560-00-765-1101 | 2011-10-03 | 16 | DIBBS |
| 1560-00-765-1101 | 2011-06-21 | 33 | DIBBS |
| 1560-00-765-1101 | 2010-02-11 | 2 | DIBBS |
| 1560-00-765-1101 | 2010-02-11 | 2 | DIBBS |
| 1560-00-765-1101 | 2010-02-11 | 5 | DIBBS |
| 1560-00-765-1101 | 2008-07-31 | 15 | DIBBS |
| 1560-00-765-1101 | 2007-02-01 | 36 | DIBBS |
| 1560-00-765-1101 | 2006-01-12 | 47 | DIBBS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 1560-00-765-1101
Related Products | NSN 1560-00-765-1101
1560-00-765-1102, 1560-00-765-1474, 1560-00-765-1487, 1560-00-765-1502, 1560-00-765-1690
Technical Data | NSN 1560-00-765-1101
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 4340 |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-S-5000 MIL SPEC SINGLE MATERIAL RESPONSE |
| SURFACE TREATMENT | CADMIUM |
| AIRCRAFT LOCATION | AILERON |
| AIRCRAFT MISSION DESIGN SERIES | F-5 |
| OVERALL LENGTH | 7.530 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 1560-00-765-1101
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Controlled Inventory Item Code: | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | F | The item is an Aviation Critical Safety Item/Flight Safety Critical Aircraft Part ((ACSI/FSCAP). |
| Category | Code | Description |
|---|---|---|
| NMF Description | 013220 | ALUM BEAMS |
| Less than car load rating | S | 60 |
| Less than truck load rating | S | 60.0 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
