Product Details | MASTER HYDRAULIC BRAKE CYLINDER ASSEMBLY
2530-00-728-7340 A device consisting of a reservoir and/or CYLINDER, HYDRAULIC BRAKE, MASTER with other components necessary to displace fluid from a central source for actuating the slave or wheel cylinders of a hydraulic brake system.20216300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components
Part Alternates: M34451, MC34451, H34451, H-34451, E34451, F34451, 1205, 174241, 174-241, 19089, 3778293, 5464540, 5467735, 2530-00-728-7340, 00-728-7340, 2530007287340, 007287340
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 19 FEB 1968 | 00-728-7340 | 11007 ( CYLINDER ASSEMBLY, HYDRAULIC BRAKE, MASTER ) |
Drawings & Photos | NSN 2530-00-728-7340
Cross Reference | NSN 2530-00-728-7340
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1205 | 06840 | BENDIX CORP THE |
| 174-241 | 76462 | DELCO MORAINE DIV OF GENERAL MOTORS CORP |
| 19089 | 19239 | ECHLIN INC |
| 3778293 | 11862 | GENERAL MOTORS CORP CHEVROLET MOTOR DIV |
| 5464540 | 76462 | DELCO MORAINE DIV OF GENERAL MOTORS CORP |
| 5467735 | 11862 | GENERAL MOTORS CORP CHEVROLET MOTOR DIV |
| 5467735 | 76462 | DELCO MORAINE DIV OF GENERAL MOTORS CORP |
| E34451 | 80724 | EIS BRAKE PARTS DIV OF STANDARD MOTOR PRODUCTS INC |
| F34451 | 63477 | FEDERAL MOGUL CORP SUB WAGNER BRAKE |
| H-34451 | 86403 | CHRYSLER CORP SERVICE AND PARTS OPNS |
| M34451 | 71425 | AIRTEX PRODUCTS DIV OF UIS INC |
| MC34451 | 66614 | TRW INC REPLACEMENT PARTS DIV |
| MC34451 | 76761 | C. E. NIEHOFF & CO. |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 2530-00-728-7340
Related Products | NSN 2530-00-728-7340
2530-00-728-7341, 2530-00-728-7344, 2530-00-728-7346, 2530-00-728-7348, 2530-00-728-7349
Technical Data | NSN 2530-00-728-7340
| Characteristic | Specifications |
|---|---|
| OVERALL WIDTH | 5.940 INCHES NOMINAL |
| OVERALL HEIGHT | 5.595 INCHES NOMINAL |
| BODY OUTSIDE DIAMETER | 1.500 INCHES NOMINAL |
| BODY MATERIAL | STEEL |
| BORE DIAMETER | 1.250 INCHES NOMINAL |
| MOUNTING TYPE AND LOCATION | FLANGE PISTON ROD END |
| MOUNTING PROVISION | UNTHREADED MOUNTING HOLES |
| MOUNTING PROVISION ARRANGEMENT STYLE | 13 THREE HOLE TRIANGULAR |
| LONGEST HORIZONTAL DISTANCE BETWEEN MOUNTING CENTERS | 5.000 INCHES NOMINAL |
| SHORTEST HORIZONTAL DISTANCE BETWEEN MOUNTING CENTERS | 2.500 INCHES NOMINAL |
| LONGEST VERTICAL DISTANCE BETWEEN MOUNTING CENTERS | 2.250 INCHES NOMINAL |
| MOUNTING FACILITY DIAMETER | 0.400 INCHES NOMINAL |
| PORT LOCATION AND QUANTITY | 1 CYLINDER HEAD END |
| PORT STYLE | 7 INVERTED FLARE |
| PORT THREAD SERIES DESIGNATOR | UNF |
| PORT THREAD DIAMETER | 0.438 INCHES NOMINAL |
| PORT THREAD QUANTITY PER INCH | 24 |
| PORT THREAD CLASS | 2B |
| SEAT ANGLE IN DEG | 45.0 |
| BLEEDING FEATURE QUANTITY | 1 |
| RESERVOIR TYPE | INTEGRAL |
| ACTUATION METHOD | DIRECT |
| SPECIAL FEATURES | TWO CYLINDER SAME SIZE |
Restrictions/Controls & Freight Information | NSN 2530-00-728-7340
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 018400 | AUTO BRAKES/SHOES R PADS ETC |
| Less than car load rating | ||
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2530-00-728-7340
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | X | SEMIACTIVE ITEM-NO REPLACEMENT (NON-STOCKED ITEMS) A potentially inactive NSN which must be retained in the supply system as an item of supply because (1) stocks of the item are on hand or in use below the wholesale level and (2) the NSN is cited in equipment authorization documents TO & E, TA, TM, etc., or in-use assets are being reported. 1. Items are authorized for central procurement but not authorized for stockage at wholesale level. 2. Requisitions for in-use replacement will be authorized in accordance with individual Military Service directives. 3. Requisitions may be submitted as requirements generate. Repetitive demands may dictate an AAC change to permit wholesale stockage. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
