Product Details | IGNITION COIL
2920-00-888-0591 An item specifically designed to produce the high voltage necessary to provide a spark for igniting combustible mixtures, primarily in internal combustion engines.20229200048Engine Electrical System Components, Nonaircraft29250058Engine Electrical System Components, Aircraft Prime Moving
Part Alternates: 10-187600-2, 10-381200-3, 36032815, 3603281-5, 377869, 40678, 42662, 2920-00-888-0591, 00-888-0591, 2920008880591, 008880591, 101876002, 103812003
Engine Accessories | Engine Electrical System Components, Nonaircraft
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 01 JAN 1962 | 00-888-0591 | 00303 ( COIL, IGNITION ) |
Drawings & Photos | NSN 2920-00-888-0591
Demand History | NSN 2920-00-888-0591
Cross Reference | NSN 2920-00-888-0591
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10-187600-2 | 59501 | UNISON INDUSTRIES, LLC |
| 10-187600-2 | 77820 | AMPHENOL CORPORATION DBA AMPHENOL AEROSPACE INDUSTRIAL |
| 10-187600-2 | R1120 | SATAIR A/S |
| 10-381200-3 | 59501 | UNISON INDUSTRIES, LLC |
| 10-381200-3 | 77820 | AMPHENOL CORPORATION DBA AMPHENOL AEROSPACE INDUSTRIAL |
| 10-381200-3 | R1120 | SATAIR A/S |
| 3603281-5 | 99193 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 377869 | 72599 | ALLIEDSIGNAL INC DBA ALLIED-SIGNAL AEROSPACE CO |
| 377869 | 99193 | HONEYWELL INTERNATIONAL INC. DBA HONEYWELL |
| 40678 | 83311 | UNISON INDUSTRIES, LLC |
| 42662 | 59501 | UNISON INDUSTRIES, LLC |
| 42662 | 83311 | UNISON INDUSTRIES, LLC |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 2920-00-888-0591
Related Products | NSN 2920-00-888-0591
2920-00-888-2428, 2920-00-888-2792, 2920-00-888-2796, 2920-00-888-2861, 2920-00-888-4985
Technical Data | NSN 2920-00-888-0591
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | 16 BASE MOUNTED |
| WIDTH | 2.688 INCHES NOMINAL |
| LENGTH | 5.680 INCHES NOMINAL |
| FIRST MOUNTING HOLE DIAMETER | 0.225 INCHES NOMINAL |
| SECOND MOUNTING HOLE DIAMETER | 0.225 INCHES NOMINAL |
| THIRD MOUNTING HOLE DIAMETER | 0.225 INCHES NOMINAL |
| FOURTH MOUNTING HOLE DIAMETER | 0.225 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN FIRST AND SECOND MOUNTING HOLES | 3.330 INCHES NOMINAL |
| CENTER TO CENTER DISTANCE BETWEEN FIRST AND THIRD MOUNTING HOLES | 2.000 INCHES NOMINAL |
| DISTANCE FROM BASE OF COIL TO MOUNTING | 1.875 INCHES NOMINAL |
| HEIGHT | 2.625 INCHES NOMINAL |
| DC PRIMARY VOLTAGE RATING | 10.0 VOLTS MINIMUM AND 20.0 VOLTS MAXIMUM |
| HIGH VOLTAGE TERMINAL TYPE | THREADED STUD |
| HIGH VOLTAGE TERMINAL QUANTITY | 1 |
| LOW VOLTAGE TERMINAL TYPE | THREADED STUD |
| LOW VOLTAGE TERMINAL QUANTITY | 1 |
| GROUND TERMINAL | PROVIDED |
| INCLOSURE MATERIAL TYPE | METALLIC |
| SUBMERSIBILITY | NONSUBMERSIBLE |
| RADIO INTERFERENCE SHIELDING | NOT PROVIDED |
Restrictions/Controls & Freight Information | NSN 2920-00-888-0591
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | Y | Information is in the Hazardous Materials Information System (HMIS) |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Hazardous Control Code: | A2 | Radioactive, License Exempt RADIOACTIVE, EXEMPT |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063120 | SPARK COILS IN BOXES/PKGS 1241/1273 |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2920-00-888-0591
Army
Navy| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
