NSN 4920-00-944-8357 657819, 661540, GT3
Product Details | GYRO TEST STATION
4920-00-944-8357 A group of items containing a console(s) and/or peripheral equipment specifically designed to provide appropriate instrumentation and data acquisition/control logic for testing gyro's and/or components.
Part Alternates: 657819, 661540, GT3, 4920-00-944-8357, 00-944-8357, 4920009448357, 009448357
Maintenance and Repair Shop Equipment | Aircraft Maintenance and Repair Shop Specialized Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 49 | 16 FEB 1966 | 00-944-8357 | 41410 ( TEST STATION, GYRO ) |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4920-00-944-8357
Technical Data | NSN 4920-00-944-8357
| Characteristic | Specifications |
|---|---|
| SPECIAL FEATURES | C/O SIGNAL CONTROL PANEL; DC NULL DETECTOR AND VTVM; SERVO AMPLIFIER; TORQUER BIAS PANEL; OSCILLOSCOPE; SIX-CHANNEL RECORDER; SERVO AMPLIFIER POWER SUPPLY; METER PANEL; TEMP RECORDER; TEMP CONTROL PANEL; PULSED 30 WHEEL SUPPLY; POWER PANEL; OSCILLATOR; COUNTER; COUNTER SIGNAL PANEL; POWER CONTROL PANEL; WATTMETER; FILAMENT SUPPLY; 250.0 VDC POWER SUPPLY; 300.0 VDC POWER SUPPLY; POWER JUNCTION BOX; PEDESTAL; BLOWER; HEATER; GIMBAL ASSY; OPTICAL BLOCK; MIRROR; CABLE ASSEMBLIES; 115.0 VAC NOMINAL,60.0-400.0 HZ,SINGLE/THREE PHASE |
| III FUNCTIONAL CLASSIFICATION | AA-9.6 |
| III FUNCTIONAL DESCRIPTION | USED TO CHECK AXIS ALIGNMENT,MEASURE/CHECK SCALE FACTOR AND TORQUER RESISTANCE OF THE GYRO UNDER TEST |
| III REFERENCE DATA AND LITERATURE | T.O. 33D7-63-5-1 |
Restrictions/Controls & Freight Information | NSN 4920-00-944-8357
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061700 | ELEC APPLIANCES/INSTRUMENTS NOI |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | L | Sets or systems that must move together to the consignee. |
| Special Handling Code | L | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
