Product Details | EXTERNALLY THREADED RING
5365-00-723-6283 A cylindrically shaped item with a concentric bore and a peripheral thread over its entire length or over a portion thereof. One face is drilled, slotted, knurled, or has projecting lugs for installation and/or removal purposes. Excludes RETAINER, OPTICAL ELEMENT.202132500005365000000
Part Alternates: 12418, 677B10018, 5365-00-723-6283, 00-723-6283, 5365007236283, 007236283
Hardware and Abrasives | Bushings, Rings, Shims, and Spacers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01 JAN 1963 | 00-723-6283 | 08417 ( RING, EXTERNALLY THREADED ) |
Drawings & Photos | NSN 5365-00-723-6283
Cross Reference | NSN 5365-00-723-6283
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12418 | 99643 | EATON CORPORATION DBA EATON AEROSPACE |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5365-00-723-6283
Related Products | NSN 5365-00-723-6283
5365-00-723-6358, 5365-00-723-6417, 5365-00-723-6599, 5365-00-723-6727, 5365-00-723-7132
Technical Data | NSN 5365-00-723-6283
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY, QQ-A-268, T4-CANCELED |
| SURFACE TREATMENT | ANODIZED |
| OVERALL LENGTH | 0.513 INCHES NOMINAL |
| MATERIAL HARDNESS RATING | NOT RATED |
| CASEHARDENING INDICATOR | NOT CASEHARDENED |
| DRIVE TYPE | SLOTTED FACE |
| ACCOMMODATION TYPE AND QUANTITY | 1 SLOTS |
| WIDTH | 0.0625 INCHES NOMINAL |
| DEPTH | 0.03125 INCHES NOMINAL |
| ANGLE BETWEEN ACCOMMODATIONS IN DEG | 360.0 |
| THREAD SIZE | 5/8 IN. -24 |
| SCREW THREAD SERIES DESIGNATOR | UNEF |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| BEVELED THREAD | INCLUDED |
| THREAD LOCATION | BOTH ENDS |
| BORE SHAPE | STRAIGHT |
| BORE DIAMETER | 0.450 INCHES NOMINAL |
| BORE ANNULAR INTERNAL SERRATION | NOT INCLUDED |
| SETSCREW LOCKING NOTCH | NOT INCLUDED |
| III FSC APPLICATION DATA | VALVE HYDRAULIC ACFT |
| MANUFACTURERS CODE | 99643 |
| DESIGN CONTROL REFERENCE | 12418 |
Restrictions/Controls & Freight Information | NSN 5365-00-723-6283
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI |
| Less than car load rating | Q | 70 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5365-00-723-6283
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
