Product Details | LUG TERMINAL
5940-00-156-7205 A terminal designed to be affixed, usually at one end, to a post, stud, chassis, or the like for mounting. It has provisions for attachment of wire(s) or similar electrical conductor(s) in order to establish an electrical connection and could require the use of tool(s) for attachment of wire. For post like terminals, see TERMINAL STUD. Excludes CLIP, ELECTRICAL; TERMINAL, QUICK DISCONNECT and TERMINAL FEEDTHRU.
Part Alternates: B4040784, SMB6508024, SMB650802-4, T8007331PC350, G6034721, G603472-1, 32054-0121, 7612528, 9902041, 990204-1, 10512075-1, 1069, 10-69, 110, 11014, 110-1-4, 110250BHT, 110-250BHT, 110257, 110-257, 1490230024, 149-023-0024, 2271367P1, 227-1367P1, 319521PC310, 319521PC350, 5940-00-156-7205, 00-156-7205, 5940001567205, 105120751, 001567205, 320540121
Electrical and Electronic Equipment Components | Lugs, Terminals, and Terminal Strips
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-156-7205 | 00746 ( TERMINAL, LUG ) |
Drawings & Photos | NSN 5940-00-156-7205
Demand History | NSN 5940-00-156-7205
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 11014 | 2023-11-15 | 100 | US |
| 11014 | 2023-11-15 | 250 | US |
| 11014 | 2023-11-15 | 500 | US |
| 11014 | 2023-09-22 | 100 | US |
| 11014 | 2023-09-22 | 250 | US |
| 11014 | 2023-09-22 | 500 | US |
| 11014 | 2020-08-21 | 120 | United States |
| 11014 | 2020-08-21 | 250 | United States |
| 1069 | 2020-07-02 | 1 | us |
| 11014 | 2019-10-18 | 250 | United States |
| 110 | 2019-08-30 | 1 | |
| 110 | 2015-05-06 | 1 | |
| 11014 | 2014-05-21 | 6 | United States |
Cross Reference | NSN 5940-00-156-7205
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 10-69 | 63060 | HEICO OHMITE LLC DBA OHMITE MFG CO INC |
| 10512075-1 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 110 | 79963 | ZIERICK MFG CORP |
| 110 | 94375 | AUTOMATIC CONNECTOR |
| 110-1-4 | 79963 | ZIERICK MFG CORP |
| 110-250BHT | 79963 | ZIERICK MFG CORP |
| 110-257 | 79963 | ZIERICK MFG CORP |
| 149-023-0024 | 95542 | NORTHROP GRUMMAN SYSTEMS CORPORATION |
| 227-1367P1 | 3B150 | RAYTHEON TECHNICAL SERVICES COMPANY LLC |
| 227-1367P1 | 49956 | RAYTHEON COMPANY DBA RAYTHEON |
| 319521PC310 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 319521PC350 | 10001 | NAVAIR AND NAVSEA MANAGED ORIGINAL DESIGN ACTIVITY DWG NOT |
| 32054-0121 | 27914 | HONEYWELL INTERNATIONAL INC DBA HONEYWELL |
| 7612528 | 18876 | U S ARMY AVIATION AND MISSILE COMMAND |
| 990204-1 | 00752 | EDO CORPORATION DIV EDO CORPORATION AP&T |
| B4040784 | 56996 | DEPARTMENT OF THE ARMY HQ UNITED STATES ARMY COMMUNICATIONS |
| G603472-1 | 06KW9 | LUCENT TECHNOLOGIES INC DBA FEDERAL MARKETING GROUP |
| G603472-1 | 64959 | AMERICAN TELEPHONE AND TELEGRAPH CO |
| G603472-1 | 70408 | AT AND T CORP |
| G603472-1 | 79963 | ZIERICK MFG CORP |
| SMB650802-4 | 80063 | US ARMY COMMUNICATIONS & ELECTRONICS MATERIEL READINESS |
| T8007331PC350 | 24446 | GENERAL ELECTRIC CO |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5940-00-156-7205
Related Products | NSN 5940-00-156-7205
5940-00-156-7206, 5940-00-156-7211, 5940-00-156-7213, 5940-00-156-7216, 5940-00-156-7217
Technical Data | NSN 5940-00-156-7205
| Characteristic | Specifications |
|---|---|
| BASIC SHAPE STYLE | A49 SOLDER, ANGULAR |
| OVERALL LENGTH | 0.813 INCHES |
| OVERALL WIDTH | 0.375 INCHES |
| ANGLE | 35.0 DEGREES |
| CONDUCTOR ACCOMMODATION TYPE | SLANT LUG W/ONE HOLE SINGLE END |
| LARGEST WIDTH | 0.156 INCHES SINGLE END |
| MAXIMUM CONDUCTOR SIZE ACCOMMODATED | 12 AWG |
| MOUNTING METHOD STYLE | D14 RING |
| MOUNTING HOLE DIAMETER | 0.250 INCHES |
| MOUNTING TONGUE WIDTH | 0.375 INCHES |
| MOUNTING FACILITY THICKNESS | 0.020 INCHES |
| ELECTRICAL INSULATION FEATURE | UNINSULATED |
| MATERIAL | COPPER ALLOY OVERALL |
| SURFACE TREATMENT | TIN OVERALL SINGLE LAYER |
Restrictions/Controls & Freight Information | NSN 5940-00-156-7205
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 061680 | ELEC WIRING PLUGS ETC |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 658 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5940-00-156-7205
Navy
Marines| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
| Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
H PG : Package |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
H PG : Package |
