5962-01-058-6762 A microcircuit specifically designed to generate, modify, or process electrical signals which operate with two distinct or binary states. These states are commonly referred to as on and off, true and false, high and low, or "1" and "0".
Part Alternates: F10110PC, 10110B, 10110F, 4014010-01, 5798890019, 57988-90019, 5962-01-058-6762, 01-058-6762, 5962010586762, 010586762, 401401001
