Product Details | LINEAR MICROCIRCUIT
5962-01-294-6718 A microcircuit whose output is a function of the input; that is, the output varies in a predetermined and essentially predictable manner from the input signal.
Part Alternates: SL12742, 2898435, 5962-01-294-6718, 01-294-6718, 5962012946718, 012946718
Electrical and Electronic Equipment Components | Microcircuits, Electronic
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 19 FEB 1989 | 01-294-6718 | 31778 ( MICROCIRCUIT, LINEAR ) |
Drawings & Photos | NSN 5962-01-294-6718
Demand History | NSN 5962-01-294-6718
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5962-01-294-6718
Related Products | NSN 5962-01-294-6718
5962-01-294-6719, 5962-01-294-6720, 5962-01-294-6721, 5962-01-294-6722, 5962-01-294-6723
Technical Data | NSN 5962-01-294-6718
| Characteristic | Specifications |
|---|---|
| DESIGN FUNCTION AND QUANTITY | 1 REGULATOR, VOLTAGE |
| INPUT CIRCUIT PATTERN | 1 INPUT |
| VOLTAGE RATING AND TYPE PER CHARACTERISTIC | 40.0 VOLTS MAXIMUM POWER SOURCE |
| OPERATING TEMP RANGE | -55.0 TO 125.0 DEG CELSIUS |
| TERMINAL TYPE AND QUANTITY | 8 PIN |
| TERMINAL SURFACE TREATMENT | SOLDER |
| INCLOSURE CONFIGURATION | CAN |
| INCLOSURE MATERIAL | METAL |
| BODY OUTSIDE DIAMETER | 0.350 INCHES MINIMUM AND 0.370 INCHES MAXIMUM |
| BODY HEIGHT | 0.165 INCHES MINIMUM AND 0.185 INCHES MAXIMUM |
| MAXIMUM POWER DISSIPATION RATING | 800.0 MILLIWATTS |
| STORAGE TEMP RANGE | -65.0 TO 150.0 DEG CELSIUS |
| FEATURES PROVIDED | HERMETICALLY SEALED AND ADJUSTABLE AND MONOLITHIC |
| TEST DATA DOCUMENT | 96906-MIL-STD-883 STANDARD |
