Product Details | HANDSET HOLDER
5965-00-642-9879 An item specifically designed to mechanically accommodate, suspend, and/or position a handset when not in use. May include locking device. Does not establish switching facilities.
Part Alternates: S650174464, S6501-74464, S6501-74464 TY Z-33B, S650174464TYZ33B, SYM 2676, SYM. 2676, SYM.2676, SYM2675, SYM2676, SYM432.1, SYM4321, Z-33A, Z33-A, Z33B, 6041779 PC4, 6041779PC4, Z33A, 02895012, 02-89-5012, 701021-273 , 9000S650174464, 9000-S6501-74464, 9000S6501-74464, 9000S6501-74464 Z33A, 9000S650174464Z33A, 5965-00-642-9879, 00-642-9879, 5965006429879, 006429879, 701021273
Electrical and Electronic Equipment Components | Headsets, Handsets, Microphones and Speakers
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-642-9879 | 00846 ( HOLDER, HANDSET ) |
Drawings & Photos | NSN 5965-00-642-9879
Demand History | NSN 5965-00-642-9879
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5965-00-642-9879 | 2023-12-18 | 137 | DIBBS |
| 5965-00-642-9879 | 2023-12-18 | 73 | DIBBS |
| 5965-00-642-9879 | 2023-12-03 | 137 | DIBBS |
| 5965-00-642-9879 | 2023-11-03 | 1 | United States |
| 5965-00-642-9879 | 2023-05-25 | 92 | DIBBS |
| 5965-00-642-9879 | 2023-02-15 | 2 | US |
| 5965-00-642-9879 | 2022-01-06 | 107 | DIBBS |
| 5965-00-642-9879 | 2021-04-19 | 111 | DIBBS |
| 5965-00-642-9879 | 2020-09-22 | 2 | United States |
| 5965-00-642-9879 | 2020-08-18 | 7 | US |
| 5965-00-642-9879 | 2020-06-15 | 2 | United States |
| 5965-00-642-9879 | 2020-01-30 | 4 | United States |
| 5965-00-642-9879 | 2019-10-10 | 242 | DIBBS |
| 5965-00-642-9879 | 2018-07-04 | 323 | DIBBS |
| 5965-00-642-9879 | 2018-05-04 | 3 | United States |
| 5965-00-642-9879 | 2017-07-10 | 1 | United States |
| 5965-00-642-9879 | 2017-07-10 | 2 | United States |
| 5965-00-642-9879 | 2017-03-02 | 348 | DIBBS |
| 5965-00-642-9879 | 2017-02-07 | 292 | DIBBS |
| 5965-00-642-9879 | 2016-10-04 | 380 | DIBBS |
| 5965-00-642-9879 | 2016-06-09 | 203 | DIBBS |
| 5965-00-642-9879 | 2014-06-04 | 150 | DIBBS |
| 5965-00-642-9879 | 2014-01-01 | 110 | DIBBS |
| 5965-00-642-9879 | 2011-09-20 | 0 | DIBBS |
| 5965-00-642-9879 | 2011-04-07 | 130 | DIBBS |
| SYM2675 | 2011-01-26 | 2 | US |
| 5965-00-642-9879 | 2009-04-08 | 12 | US |
| 5965-00-642-9879 | 2009-02-03 | 68 | DIBBS |
| 5965-00-642-9879 | 2009-01-02 | 85 | DIBBS |
| 5965-00-642-9879 | 2008-09-12 | 152 | DIBBS |
| 5965-00-642-9879 | 2008-01-02 | 188 | DIBBS |
| 5965-00-642-9879 | 2007-10-01 | 97 | DIBBS |
| 5965-00-642-9879 | 2007-08-29 | 74 | DIBBS |
| 5965-00-642-9879 | 2007-07-23 | 150 | DIBBS |
| 5965-00-642-9879 | 2007-06-12 | 118 | DIBBS |
| 5965-00-642-9879 | 2007-05-09 | 82 | DIBBS |
Cross Reference | NSN 5965-00-642-9879
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 02-89-5012 | 96169 | ELECTRIC BOAT CORPORATION |
| 6041779 PC4 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 701021-273 | 12763 | DYNALEC CORPORATION |
| 9000-S6501-74464 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 9000S6501-74464 | 06076 | F AND H MFG CORP |
| 9000S6501-74464 | 30396 | CENTURY METAL PARTS, CORP. |
| 9000S6501-74464 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 9000S6501-74464 Z33A | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| S6501-74464 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| S6501-74464 TY Z-33B | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| SYM 2676 | 81349 | MILITARY SPECIFICATIONS PROMULGATED BY MILITARY |
| SYM. 2676 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| SYM.2676 | 07625 | ELECTRO MECH CO |
| SYM2675 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| SYM2676 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| SYM2676 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| SYM432.1 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| Z-33A | 96169 | ELECTRIC BOAT CORPORATION |
| Z33-A | 78957 | COMDIAL BUSINESS COMMUNICATIONS CORP REPAIR DEPT |
| Z33A | 73274 | HOSE-MCCANN TELEPHONE CO., INC. DBA HOSE MCCANN COMMUNICATIONS |
| Z33A | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| Z33B | 73274 | HOSE-MCCANN TELEPHONE CO., INC. DBA HOSE MCCANN COMMUNICATIONS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5965-00-642-9879
Related Products | NSN 5965-00-642-9879
5965-00-642-9978, 5965-00-644-0195, 5965-00-644-0312, 5965-00-644-0328, 5965-00-644-0329
Technical Data | NSN 5965-00-642-9879
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY |
| SURFACE TREATMENT | NICKEL AND OXIDE |
| STYLE DESIGNATOR | 12C IRREGULAR |
| OVERALL LENGTH | 10.375 INCHES MINIMUM |
| OVERALL HEIGHT | 2.765 INCHES MAXIMUM |
| OVERALL WIDTH | 4.078 INCHES MINIMUM AND 4.875 INCHES MAXIMUM |
| ACCOMMODATED ITEM SECURING DEVICE TYPE | FRICTION FASTENER |
| MOUNTING FACILITY TYPE AND QUANTITY | 3 UNTHREADED HOLE SINGLE MOUNTING FACILITY |
| UNTHREADED MOUNTING HOLE DIAMETER | 0.266 INCHES NOMINAL SINGLE MOUNTING FACILITY |
| DISTANCE BETWEEN MOUNTING FACILITY CENTERS | 1.750 INCHES NOMINAL SINGLE MOUNTING FACILITY FIRST CENTER GROUP 2.500 INCHES NOMINAL SINGLE MOUNTING FACILITY SECOND CENTER GROUP |
| SPECIAL FEATURES | NON-MAGNETIC HOLDER FOR SOUND POWERED TELEPHONE HANDSETS; MADE FROM BRASS,BRONZE,AND BERYLLIUM COPPER |
| CRITICALITY CODE JUSTIFICATION | FEAT |
Restrictions/Controls & Freight Information | NSN 5965-00-642-9879
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095190 | HARDWARE, NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5965-00-642-9879
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
