Product Details | JUNCTION BOX COVER
5975-00-682-0344 A cover containing facilities for mounting directly on a JUNCTION BOX. It may have provisions for the insertion and/or mounting of electrical devices, such as switches, connectors, additional covers, and jewels. It may include the jewel(s). For covers having facilities for mounting on brackets or on current carrying devices such as switches and receptacle connectors, see PLATE, WALL, ELECTRICAL. See also COVER, CONDUIT OUTLET.
Part Alternates: AA59214, A-A-59214, AA592148E46, AA59214-8E46, FEDSTD128, WJ800, W-J-800, WJ800TYPE8SIZEVSTYLE64, 24HZ, 403B, 52C62, 771, 8468B, 5975-00-682-0344, 00-682-0344, 5975006820344, 006820344
Electrical and Electronic Equipment Components | Electrical Hardware and Supplies
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-682-0344 | 13702 ( COVER, JUNCTION BOX ) |
Drawings & Photos | NSN 5975-00-682-0344
Demand History | NSN 5975-00-682-0344
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AA59214 | 2020-10-07 | 2 | United States |
| 5975-00-682-0344 | 2016-02-09 | 152 | DIBBS |
| 5975-00-682-0344 | 2016-01-06 | 2 | DIBBS |
| 5975-00-682-0344 | 2015-12-29 | 2 | DIBBS |
| 5975-00-682-0344 | 2015-10-14 | 6 | DIBBS |
| 5975-00-682-0344 | 2015-10-05 | 6 | DIBBS |
| 5975-00-682-0344 | 2015-09-22 | 30 | DIBBS |
| 5975-00-682-0344 | 2014-09-17 | 2 | DIBBS |
| 5975-00-682-0344 | 2014-09-09 | 2 | DIBBS |
| AA59214 | 2010-07-22 | 3 | US |
Cross Reference | NSN 5975-00-682-0344
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 24HZ | 76655 | PORTER H K CO INC ELECTRICAL DIV AMBRIDGE WORKS |
| 403B | 90759 | NI INDUSTRIES INC BOWERS MFG CO DIV |
| 52C62 | 56501 | THOMAS & BETTS CORPORATION |
| 771 | 28488 | RACO A DIVISION OF HUBBELL INCORPORATEDDELAWARE |
| 8468B | 03743 | EGS ELECTRICAL GROUP APPLETON DIV |
| A-A-59214 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| AA59214-8E46 | 58536 | FEDERAL COMMERCIAL ITEM DESCRIPTION PROMULGATED BY GENERAL SERVICES |
| FEDSTD128 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| W-J-800 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
| WJ800TYPE8SIZEVSTYLE64 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5975-00-682-0344
Related Products | NSN 5975-00-682-0344
5975-00-682-0356, 5975-00-682-0451, 5975-00-682-0456, 5975-00-682-0461, 5975-00-682-0511
Technical Data | NSN 5975-00-682-0344
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | A9 SQUARE-CORNER MOUNTED |
| OVERALL LENGTH | 4.000 INCHES NOMINAL |
| OVERALL HEIGHT | 0.250 INCHES NOMINAL |
| OVERALL WIDTH | 4.000 INCHES NOMINAL |
| MOUNTING HOLE DIAMETER | 0.312 INCHES NOMINAL |
| FIRST CENTER TO CENTER DISTANCE BETWEEN MOUNTING HOLES | 3.312 INCHES NOMINAL |
| SECOND CENTER TO CENTER DISTANCE BETWEEN MOUNTING HOLES | 3.312 INCHES NOMINAL |
| DISTANCE FROM CENTER OF MOUNTING HOLE TO EDGE ALONG THE WIDTH | 0.344 INCHES NOMINAL |
| DISTANCE FROM CENTER OF MOUNTING HOLE TO EDGE ALONG THE LENGTH | 0.344 INCHES NOMINAL |
| COVER MOUNTING HOLE QUANTITY | 4 |
| COVER TYPE | RAISED |
| COVER OPENING SHAPE AND QUANTITY | 1 RECTANGULAR |
| STANDARD WIRING DEVICE QUANTITY | 1 |
| MATERIAL | STEEL COVER |
| SURFACE TREATMENT | ZINC OR CADMIUM COVER |
| COVER ATTACHMENT METHOD | SCREW AND SLOT |
| NONDEFINITIVE SPEC/STD DATA | E SIZE AND 46 STYLE AND VIII TYPE |
| MANUFACTURERS CODE | 58536 |
| NON-DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | A-A-59214 |
| MANUFACTURERS CODE | 58536 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | AA59214-8E46 |
Restrictions/Controls & Freight Information | NSN 5975-00-682-0344
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 063160 | SWITCH BOXES/ELEC ENCLOSURES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
