Product Details | ANTENNA COUPLER
5985-00-952-5711 A coupler which provides a means of transfer of electrical energy between an antenna and other components. See also LINE, RADIO FREQUENCY TRANSMISSION; CABLE ASSEMBLY (as modified); and NETWORK, IMPEDANCE MATCHING.
Part Alternates: CU1092U, DMM5, 6162753, 616275-3, 261C220, 5985-00-952-5711, 00-952-5711, 5985009525711, 009525711
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1962 | 00-952-5711 | 16118 ( COUPLER, ANTENNA ) |
Drawings & Photos | NSN 5985-00-952-5711
Demand History | NSN 5985-00-952-5711
Cross Reference | NSN 5985-00-952-5711
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 261C220 | 00752 | EDO CORPORATION DIV EDO CORPORATION AP&T |
| 616275-3 | 98897 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN AERONAUTICS |
| CU1092U | 80058 | JOINT ELECTRONICS TYPE DESIGNATION SYSTEM |
| DMM5 | 00752 | EDO CORPORATION DIV EDO CORPORATION AP&T |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5985-00-952-5711
Related Products | NSN 5985-00-952-5711
5985-00-952-5816, 5985-00-952-6122, 5985-00-952-7659, 5985-00-952-8961, 5985-00-952-9013
Technical Data | NSN 5985-00-952-5711
| Characteristic | Specifications |
|---|---|
| RADIO FREQUENCY RATING | 108.0 MEGAHERTZ MINIMUM AND 122.0 MEGAHERTZ MAXIMUM |
| COUPLING METHOD | INDUCTIVE-CAPACITIVE |
| TUNING TYPE | FIXED |
| POWER RATING | NOT RATED |
| TERMINAL QUANTITY | 3 |
| TERMINAL TYPE | CONNECTOR |
| MATERIAL AND LOCATION | ALUMINUM CASE |
| OVERALL LENGTH | 4.656 INCHES NOMINAL |
| OVERALL WIDTH | 2.125 INCHES NOMINAL |
| OVERALL HEIGHT | 3.593 INCHES NOMINAL |
| MOUNTING CONFIGURATION | TWO 0.221 IN. DIA MTG HOLES ON DIAGONAL CORNERS OF A RECTANGLE,SPACED ON 1.781 IN. BY 2.875 IN. CENTERS |
| III FSC APPLICATION DATA | DIRECTIONAL FINDER SET,AIRBORNE |
| MANUFACTURERS CODE | 80058 |
| DESIGN CONTROL REFERENCE | CU1092U |
