Product Details | RADOME
5985-01-176-0194 An item which incloses an antenna. It is specifically designed to permit maximum passage of radio frequency energy through it, while providing protection to the antenna from weather. The item may also inclose the antenna support, and rotating mechanism. It may be flexible or rigid, streamlined or irregular shaped. May also include pressurizing mechanism and anti-icing or de-icing equipment. See also COVER, ANTENNA ELEMENT.20215600030Airframe Structural Components59850043Antennas, Waveguides, and Related Equipment
Part Alternates: 10177179 , 3254091501, 3254091-501, 5985-01-176-0194, 01-176-0194, 5985011760194, 011760194
Electrical and Electronic Equipment Components | Antennas, Waveguides, and Related Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 06 APR 1984 | 01-176-0194 | 16132 ( RADOME ) |
Drawings & Photos | NSN 5985-01-176-0194
Demand History | NSN 5985-01-176-0194
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5985-01-176-0194 | 2019-03-22 | 1 | us |
| 3254091501 | 2019-03-14 | 1 | US |
| 5985-01-176-0194 | 2019-03-07 | 25 | Spain |
| 5985-01-176-0194 | 2017-06-05 | 19 | DIBBS |
| 5985-01-176-0194 | 2017-05-24 | 19 | DIBBS |
| 5985-01-176-0194 | 2016-01-14 | 21 | DIBBS |
| 5985-01-176-0194 | 2010-09-10 | 1 | Spain |
| 5985-01-176-0194 | 2010-07-20 | 1 | Spain |
| 5985-01-176-0194 | 2010-06-04 | 1 | Spain |
| 5985-01-176-0194 | 2010-04-15 | 1 | Spain |
| 5985-01-176-0194 | 2009-04-08 | 86 | DIBBS |
Cross Reference | NSN 5985-01-176-0194
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 3254091-501 | 93346 | SENSOR AND ANTENNA SYSTEMS, LANSDALE, INC. |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5985-01-176-0194
Related Products | NSN 5985-01-176-0194
5985-01-176-0290, 5985-01-176-0621, 5985-01-176-0622, 5985-01-176-1526, 5985-01-176-1736
Technical Data | NSN 5985-01-176-0194
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 3.480 INCHES MINIMUM AND 3.520 INCHES MAXIMUM |
| OVERALL DIAMETER | 3.400 INCHES MINIMUM AND 3.420 INCHES MAXIMUM |
| RADOME FLEXIBILITY | RIGID |
| INFLATED RADOME SHAPE | SEMISPHERICAL |
| MATERIAL | ALUMINUM ALLOY, 6061, T6 |
| PRESSURIZING DEVICE | NOT INCLUDED |
| ANTI-ICING PROVISION | NOT INCLUDED |
| DE-ICING PROVISION | NOT INCLUDED |
| SPECIAL FEATURES | WEAPON SYSTEM ESSENTIAL |
| CRITICALITY CODE JUSTIFICATION | FEAT |
| III END ITEM IDENTIFICATION | F/A-18 HORNET AIRCRAFT. |
| III USAGE DESIGN | RADAR SET GROUP |
| III SUPPLEMENTARY FEATURES | MARK "DO NOT PAINT" WITH 0.750 IN. HIGH LETTERS |
| III FSC APPLICATION DATA | ANTENNAS,WAVEGUIDES,AND RELATED EQUIP. |
Restrictions/Controls & Freight Information | NSN 5985-01-176-0194
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | D | Munitions List Item or Commerce Control List Item. Demilitarization required. Total destruction of the item and components so as to preclude restoration or repair to a usable condition by melting, cutting, tearing, scratching, crushing, breaking, punching, neutralizing, etc. (As an alternate, burial or deep water dumping may be used when coordinated with the DoD Demilitarization Program Office.) |
| Controlled Inventory Item Code: | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 011790 | AIRCRAFT PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | TX | Defense Supply Center Columbus Columbus, OH 43218 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 5985-01-176-0194
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | 7 | NON-SENSITIVE (SRC-N/A) - UNCLASSIFIED AA&E: OR ITEMS ASSIGNED A DEMILITARIZATION CODE OTHER THAN A, B, Q, OR P FOR WHICH ANOTHER CIIC IS INAPPROPRIATE. (NOTE: THE LOSS, THEFT, UNLAWFUL DISPOSITION, AND/OR RECOVERY OF AN ITEM WITH CIIC 7 WILL BE INVESTIGATED IN ACCORDANCE WITH DOD-4000-25-2-M AND DOD 7200.14-R, VOLUME 12, CHAPTER 7). |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
