Product Details | CONTROL MOTOR
6105-01-012-4176 A motor which is designed to be operated from two independent voltage sources, in such a way that variations in one voltage source will determine the direction and speed of the motor. In the alternating current type the voltages are usually applied to a split-phase stator, whereas in the direct current type, one voltage is applied to the stator and the other to the armature. Low inertia and rapid reversibility are inherent characteristics of this type of motor. See also SERVOMOTOR, AUTOMATIC PILOT.
Part Alternates: CK107245A2, CK1072-45-A2, 10581953-1, 6105-01-012-4176, 01-012-4176, 6105010124176, 105819531, 010124176
Electric Wire, and Power and Distribution Equipment | Motors, Electrical
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 11 NOV 1975 | 01-012-4176 | 19258 ( MOTOR, CONTROL ) |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 6105-01-012-4176
6105-01-012-7080, 6105-01-012-7081, 6105-01-012-7082, 6105-01-012-8676, 6105-01-012-9219
Technical Data | NSN 6105-01-012-4176
| Characteristic | Specifications |
|---|---|
| OVERALL LENGTH | 1.758 INCHES |
| OVERALL WIDTH | 1.061 INCHES |
| LENGTH OF SHAFT FROM HOUSING | 0.305 INCHES SINGLE END |
| MOUNTING METHOD | CLAMP RING |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 CLAMP COLLAR |
| INCLOSURE FEATURE | TOTALLY INCLOSED |
| TERMINAL TYPE AND QUANTITY | 4 WIRE LEAD |
| SHAFT END CHARACTERISTIC | A14 SINGLE STYLE SINGLE END |
| SHAFT DIAMETER | 0.120 INCHES MINIMUM AND 0.121 INCHES MAXIMUM SINGLE END |
| SPLINE LENGTH | 0.3050 INCHES NOMINAL SINGLE END |
| SPLINE QUANTITY | 12 SINGLE END |
| FEATURES PROVIDED | HORIZONTAL MOUNTING POSITION AND VERTICAL MOUNTING POSITION |
| MANUFACTURERS CODE | 55973 |
| DESIGN CONTROL REFERENCE | CK1072-45-A2 |
Restrictions/Controls & Freight Information | NSN 6105-01-012-4176
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062120 | GENERATORS/MOTORS/PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 593 | unknown |
| Originating Activity Code | CX | Defense Supply Center Richmond Richmond, VA 23297-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
