Product Details | POWER SUPPLY ASSEMBLY
6130-01-257-8868 Two or more independent power supplies having a common mounting or mounted on each other.
Part Alternates: STCC64D0561, STCC64D056-1, 188213, 18821-3, 188214, 18821-4, 863G1300000, 6130-01-257-8868, 01-257-8868, 6130012578868, 012578868
Electric Wire, and Power and Distribution Equipment | Converters, Electrical, Nonrotating
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 61 | 25 JUN 1987 | 01-257-8868 | 00295 ( POWER SUPPLY ASSEMBLY ) |
Drawings & Photos | NSN 6130-01-257-8868
Demand History | NSN 6130-01-257-8868
Cross Reference | NSN 6130-01-257-8868
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 18821-3 | 80103 | VEECO INSTRUMENTS INC LAMBDA DIV |
| 18821-4 | 80103 | VEECO INSTRUMENTS INC LAMBDA DIV |
| 863G1300000 | 04236 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN SPACE SYSTEMS |
| STCC64D056-1 | 04236 | LOCKHEED MARTIN CORPORATION DBA LOCKHEED MARTIN SPACE SYSTEMS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 6130-01-257-8868
Related Products | NSN 6130-01-257-8868
6130-01-257-8869, 6130-01-257-8870, 6130-01-257-8871, 6130-01-257-8872, 6130-01-257-8873
Technical Data | NSN 6130-01-257-8868
| Characteristic | Specifications |
|---|---|
| OUTPUT VOLTAGE RATING | 100.0 DC VOLTS NOMINAL 1ST POWER OUTPUT 48.0 DC VOLTS NOMINAL 2ND POWER OUTPUT 0.0 DC VOLTS MINIMUM AND 18.0 DC VOLTS MAXIMUM 3RD POWER OUTPUT 15.0 DC VOLTS NOMINAL 4TH POWER OUTPUT 15.0 DC VOLTS NOMINAL 5TH POWER OUTPUT 5.0 DC VOLTS NOMINAL 6TH POWER OUTPUT |
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| INPUT VOLTAGE RATING | 105.0 AC VOLTS MINIMUM AND 127.0 AC VOLTS MAXIMUM SINGLE OPERATING POWER RQMT |
| INPUT FREQUENCY RATING | 47.0 HERTZ MINIMUM AND 44.0 HERTZ MAXIMUM SINGLE OPERATING POWER RQMT |
| INPUT PHASE | SINGLE SINGLE OPERATING POWER RQMT |
| POWER UNIT QUANTITY | 6 |
| OVERALL LENGTH | 22.930 INCHES NOMINAL |
| OVERALL WIDTH | 19.000 INCHES NOMINAL |
| OVERALL HEIGHT | 5.220 INCHES NOMINAL |
| OPERATING AMBIENT TEMP RANGE | -0.0 TO 60.0 DEG CELSIUS |
| FEATURES PROVIDED | VOLTAGE ADJUSTMENT |
| III END ITEM IDENTIFICATION | DOWN STAGE SIMULATOR |
| MANUFACTURERS CODE | 80103 |
| DESIGN CONTROL REFERENCE | 18821-4 |
Restrictions/Controls & Freight Information | NSN 6130-01-257-8868
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | C | Munitions List Item or Commerce Control List Item. Demilitarization required. Remove and/or demilitarize installed key point(s) as prescribed in the Defense Demilitarization Manual, or lethal parts, components and accessories. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062900 | RECTIFIERS NOI/BATTERY ELIMINATORS |
| Less than car load rating | M | 85 |
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 72D | unknown |
| Originating Activity Code | SU | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | Z | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
