Product Details | SIGNAL DATA RECORDER
6625-00-479-4722 An item which makes a permanent representation of electronic signal data derived from target parameters, guidance and evaluation signals, and the like, These signals may be above or below 20,000 hertz. They may be in digital and/or analog form, the characteristics of which limits useful playback to a compatable reproducer. These items usually include multichannel signal input facilities for the simultaneous recording of several types of signals. Excludes RECORDER, SOUND.20258950037Miscellaneous Communication Equipment66250070Electrical and Electronic Properties Measuring and Testing Instruments
Part Alternates: 605, 6625-00-479-4722, 00-479-4722, 6625004794722, 004794722
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 04 FEB 1970 | 00-479-4722 | 21118 ( RECORDER, SIGNAL DATA ) |
Drawings & Photos | NSN 6625-00-479-4722
Cross Reference | NSN 6625-00-479-4722
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 605 | 55026 | SIMPSON ELECTRIC COMPANY DBA (SUB OF LAC DU FLAMBEAU BAND OF |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 6625-00-479-4722
Related Products | NSN 6625-00-479-4722
6625-00-479-4723, 6625-00-479-4724, 6625-00-479-4725, 6625-00-479-4726, 6625-00-479-4729
Technical Data | NSN 6625-00-479-4722
| Characteristic | Specifications |
|---|---|
| RECORDING METHOD | SENSITIZED PAPER |
| INFORMATION RECORDED | DC VOLTS; DC CURRENT; AC VOLTS; AC CURRENT |
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| AC VOLTAGE RATING | 115.0 VOLTS NOMINAL |
| FREQUENCY RATING | 60.0 HERTZ NOMINAL |
| PHASE | SINGLE |
| OVERALL WIDTH | 4.750 INCHES NOMINAL |
| OVERALL HEIGHT | 4.000 INCHES NOMINAL |
| OVERALL DEPTH | 9.750 INCHES NOMINAL |
| SPECIAL FEATURES | MULTI-RANGE CHART RECORDERS |
| III UNPACKAGED UNIT WEIGHT | 5.500 POUNDS |
| III SUPPLEMENTARY FEATURES | 24 RANGES; 3 BUILT-IN CHART SPEEDS; INKLESS RECORDING |
