6625-00-999-2795 A test set primarily designed for use in making examinations of radar equipment. See also TEST SET, ELECTRON TUBE; MULTIMETER; OSCILLOSCOPE; GENERATOR, SIGNAL; TEST SET, DOPPLER RADAR RECEIVER; and TEST SET, AMPLIFIER.
Part Alternates: 5168161, 516816-1, 6625-00-999-2795, 00-999-2795, 6625009992795, 009992795
Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 66 | 28 JAN 1966 | 00-999-2795 | 03661 ( TEST SET, RADAR ) |
Drawings & Photos | NSN 6625-00-999-2795
Cross Reference | NSN 6625-00-999-2795
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 516816-1 | 96214 | RAYTHEON COMPANY DBA RAYTHEON |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 6625-00-999-2795
Related Products | NSN 6625-00-999-2795
6625-00-999-2911, 6625-00-999-2912, 6625-00-999-2913, 6625-00-999-3592, 6625-00-999-3663
Technical Data | NSN 6625-00-999-2795
| Characteristic | Specifications |
|---|---|
| TEST TYPE FOR WHICH DESIGNED | OFFSET CURSOR GEN SUBASSEMBLY |
| ELECTRICAL POWER SOURCE RELATIONSHIP | OPERATING |
| AC VOLTAGE RATING | 115.0 VOLTS NOMINAL |
| FREQUENCY RATING | 400.0 HERTZ NOMINAL |
| PHASE | THREE |
| DC VOLTAGE RATING | 28.0 VOLTS NOMINAL |
| INTERNAL BATTERY ACCOMMODATION | NOT INCLUDED |
| MAJOR COMPONENTS | RADAR TEST SET CONTROL TEST PANEL,SPECIAL TEST FIXTURE |
| ACCESSORY COMPONENT QUANTITY | 4 |
| SPECIAL FEATURES | MAJOR COMPONENTS MOUNTED ON ALUMINUM RACK |
| MANUFACTURERS CODE | 96214 |
| DESIGN CONTROL REFERENCE | 516816-1 |
