Product Details | DECAL
7690-00-765-3444 A design, picture, legend, or shape processed on specially prepared paper for transferring by the decalcomania process to china, glass, metal, porcelain, plastic, and like surfaces. See also MARKER, IDENTIFICATION.
Part Alternates: AAF700001, G , 673715, 7690-00-765-3444, 00-765-3444, 7690007653444, 007653444
Books, Maps, and Other Publications | Miscellaneous Printed Matter
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 76 | 01 JAN 1962 | 00-765-3444 | 03194 ( DECAL ) |
Drawings & Photos | NSN 7690-00-765-3444
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 7690-00-765-3444
7690-00-768-3672, 7690-00-768-3673, 7690-00-768-4781, 7690-00-769-9734, 7690-00-769-9735
Technical Data | NSN 7690-00-765-3444
| Characteristic | Specifications |
|---|---|
| MARKING DESIGNATION | LEGEND |
| INSCRIPTION | PARTIAL LEGEND WARNING,INSPECTCRYSTALS WEEKLY - IF ANY CRYSTALS APPEAR LIGHT BLUE ORPINK IN COLOR,THEY MUST BE REACTIVATED IMMEDIATELY TO/-----/ |
| COLOR | BLACK INSCRIPTION WHITE INSCRIPTION BACKGROUND |
| BASIC SHAPE STYLE | A2 RECTANGULAR |
| WIDTH | 4.000 INCHES NOMINAL |
| LENGTH | 1.562 INCHES NOMINAL |
| MANUFACTURERS CODE | 74048 |
| DESIGN CONTROL REFERENCE | G |
Restrictions/Controls & Freight Information | NSN 7690-00-765-3444
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 152900 | PAPER DECALCOMANIAS/HEAT TRNSF |
| Less than car load rating | J | 100.2 |
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 721 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | S | Office, School, and Household Supplies/Equipment including Office Machines, Furniture/Stationary, Films, Synthetic/Special Training Films, Non-Hazardous Household Cleaning Products, Non-Hazardous Personal Hygiene Products, etc. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
