Product Details | BAND PASS FILTER
5915-00-151-7840 An item designed to pass frequencies within a specified range (band) and to suppress frequencies outside the range (band). Excludes a single inductance, or a single capacitance, or a single resistance. See COIL (as modified); REACTOR; CAPACITOR (as modified); and RESISTOR (as modified).
Part Alternates: ZM3REVD, 14981, 5915-00-151-7840, 00-151-7840, 5915001517840, 001517840
Electrical and Electronic Equipment Components | Filters and Networks
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 01 JAN 1963 | 00-151-7840 | 00209 ( FILTER, BAND PASS ) |
Drawings & Photos | NSN 5915-00-151-7840
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 5915-00-151-7840
Related Products | NSN 5915-00-151-7840
5915-00-151-7848, 5915-00-151-7849, 5915-00-152-4016, 5915-00-152-7517, 5915-00-152-9624
Technical Data | NSN 5915-00-151-7840
| Characteristic | Specifications |
|---|---|
| REFERENCE FREQUENCY PER FUNCTION | 2.55 KILOHERTZ BLANK |
| FREQUENCY BAND WIDTH PER FUNCTION | 1.45 KILOHERTZ BLANK AND 3.65 KILOHERTZ BLANK |
| INPUT IMPEDANCE PER FUNCTION W/LOAD | 600.0 OHMS BLANK |
| OUTPUT IMPEDANCE PER FUNCTION W/SOURCE ACROSS INPUT | 600.0 OHMS BLANK |
| INCLOSURE TYPE | HERMETICALLY SEALED |
| MOUNTING FACILITY TYPE AND QUANTITY | 1 THREADED STUD |
| MOUNTING FACILITY SCREW THREAD SERIES DESIGNATOR | UNC |
| NOMINAL THREAD SIZE | 0.164 INCHES |
| MANUFACTURERS CODE | 57057 |
| DESIGN CONTROL REFERENCE | ZM3REVD |
