NSN 6625-01-067-6783 1891370, T885, 01-067-6783

Product Details | RADIO TEST SET


6625-01-067-6783 A test set primarily designed for use in making examinations of radio equipment. See also TEST SET, ELECTRON TUBE; MULTIMETER; OSCILLOSCOPE; GENERATOR, SIGNAL; and TEST SET, AMPLIFIER.

Part Alternates: 1891370, T885, 6625-01-067-6783, 01-067-6783, 6625010676783, 010676783

Instruments and Laboratory Equipment | Electrical and Electronic Properties Measuring and Testing Instruments

Supply Group (FSG) NSN Assign. NIIN
66 04 NOV 1978 01-067-6783

Drawings & Photos | NSN 6625-01-067-6783




Cross Reference | NSN 6625-01-067-6783


Part Number Cage Code Manufacturer
1891370 03956 NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NAVAL AND MARINE SYSTEMS
T885 03956 NORTHROP GRUMMAN SYSTEMS CORPORATION DIV NAVAL AND MARINE SYSTEMS

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 6625-01-067-6783


Technical Data | NSN 6625-01-067-6783


Characteristic Specifications
TEST TYPE FOR WHICH DESIGNED POWER; RECEIVER CIRCUITS
ELECTRICAL POWER SOURCE RELATIONSHIP OPERATING
AC VOLTAGE RATING 115.0 VOLTS NOMINAL
FREQUENCY RATING 60.0 HERTZ NOMINAL AND 400.0 HERTZ NOMINAL
DC VOLTAGE RATING 27.0 VOLTS NOMINAL
INCLOSURE FEATURE MULTIPLE ITEM W/HOUSING
DEPTH 31.500 INCHES NOMINAL
HEIGHT 65.000 INCHES NOMINAL
WIDTH 45.000 INCHES NOMINAL
MAJOR COMPONENTS MULTICOUNTER; DIGITAL MULTIMETER; DUAL-CHANNEL OSCILLOSCOPE; DIGITAL MARKER; GENERATOR/SWEEPER; PULSE GENERATOR; SYSTEM NOISE MONITOR
III END ITEM IDENTIFICATION AN/APN 59E(V)5841010535763 RADAR SET

Restrictions/Controls & Freight Information | NSN 6625-01-067-6783


Category Code Description
Shelf-Life Code:0Nondeteriorative
Hazardous Material Indicator CodePThere is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product
Demilitarization Code:BMunitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.)
Controlled Inventory Item Code:UUNCLASSIFIED
Precious Metals Indicator Code:AItem does not contain precious metal
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Automatic Data Processing Equipment:0Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9)
Category Code Description
NMF Description 061700 ELEC APPLIANCES/INSTRUMENTS NOI
Less than car load rating P 77.5
Less than truck load rating J 100.2
Water commodity Code 738 unknown
Originating Activity Code TG Warner-Robins Air Logistics Center
Robins AFB, GA 31098-5609
Air Dimension Code A Shipment is not a consolidation and does not exceed 72 inches in any dimension.
Air Commodity H Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc.
Air Special Handling Q Extremely fragile items including delicate instruments.
Special Handling Code 9 unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable

Management | NSN 6625-01-067-6783


Category Code Description
Materiel Management Aggregation CodeCWTG:AIRBORNE RADAR AND MISCELLANEOUS ELECTRONIC EQUIPMENT
Price ValidationN The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
  • The price has not been analyzed or reviewed for accuracy.
  • ZOP or Standard price challenges are permissible, but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of ?L? or?F?,the case must be evaluated locally where purchased or fabricated.
Fund CodeROMajor repair.
Budget CodeY variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly.
Source of SupplyFLZWarner Robins Air Logistics Center
Robins AFB, GA 31098-5609
AgencyDFDepartment of the Air Force
Service OrganizationLLead Service - 22 (Repairable)
ReparabilitySAF Equipment Management System (AFEMS)
Acquisition Advice CodesMRESTRICTED REQUISITIONS-MAJOR OVERHAUL (Service/Agency use only.) # Items (Assemblies and/or component parts) which for lack of specialized tools, test equipment, etc., can be used only by major overhaul activities. Base, post, camp or station activities will not requisition unless authorized to perform major overhaul function.
Controlled Item CodeUUNCLASSIFIED
Shelf Life Code0Nondeteriorative
Purchasing QTY
UOM
1
EA : Each
