Product Details | SOLID STATE RELAY
5945-01-605-8040 A self-contained device that performs the function of opening or closing an electrical circuit in response to electrical changes in an external circuit. In lieu of separable contacts and their actuator(s), the switching function is accomplished by means of an arrangement of semiconductors and passive circuit devices. The device is designed to have electrical isolation between control circuit and output circuit. Excludes RELAY, HYBRID.
Part Alternates: V210K90DC, V210-K-90-D-C, 5945-01-605-8040, 01-605-8040, 5945016058040, 016058040
Electrical and Electronic Equipment Components | Relays and Solenoids
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 59 | 25 APR 2012 | 01-605-8040 | 31446 ( RELAY, SOLID STATE ) |
Cross Reference | NSN 5945-01-605-8040
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| V210-K-90-D-C | 58657 | LEACH INTERNATIONAL CORPORATION DBA LEACH INTERNATIONAL NORTH |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 5945-01-605-8040
5950-00-581-8874, 5950-00-633-7655, 5950-00-888-9239, 5950-01-025-9667, 5950-01-044-5038
Technical Data | NSN 5945-01-605-8040
| Characteristic | Specifications |
|---|---|
| OVERALL WIDTH | 1.531 INCHES MAXIMUM |
| PRECIOUS MATERIAL AND LOCATION | 0PINS GOLD |
| TERMINAL TYPE AND QUANTITY | 17 PIN |
| OVERALL HEIGHT | 2.340 INCHES MAXIMUM |
| OPERATING TEMP RANGE | -55.0 TO 85.0 DEG CELSIUS |
| OVERALL LENGTH | 2.187 INCHES MAXIMUM |
| SPECIAL FEATURES | TRIP POINT:90 VOLTS RMS,3 MOUNTING HOLES 213.0 TO 223.0 INCH DIA,VOLTAG E RANGE:90.0 TO 124.0 |
Restrictions/Controls & Freight Information | NSN 5945-01-605-8040
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | G | Item contains gold |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
