Product Details | MULTIPLE DISK BRAKE
1630-00-847-3731 A brake consisting essentially of the following: a. A brake anchor bracket, also called a carrier assembly, which is the basic unit of the brake. It is designed to be attached to the torque flange of the axle and is also the part upon which the other components of the brake are assembled. b. A floating hydraulically actuated annular piston, or an equivalent mechanical device, used for applying braking pressure. c. Metallic disks keyed to rotate with the wheel alternated with nonrotating disks keyed to the anchor bracket. See also BRAKE, SEGMENTED ROTOR.20316300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components30400042Miscellaneous Power Transmission Equipment
Part Alternates: 9550404, 1630-00-847-3731, 00-847-3731, 1630008473731, 008473731
Aircraft Components and Accessories | Aircraft Wheel and Brake Systems
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 16 | 27 SEP 1967 | 00-847-3731 | 09195 ( BRAKE, MULTIPLE DISK ) |
Drawings & Photos | NSN 1630-00-847-3731
Demand History | NSN 1630-00-847-3731
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 1630-00-847-3731 | 2021-06-03 | 10 | SV |
| 1630-00-847-3731 | 2021-05-27 | 10 | SV |
| 9550404 | 2018-08-22 | 2 | us |
| 1630-00-847-3731 | 2018-08-14 | 2 | United States |
| 1630-00-847-3731 | 2017-08-24 | 3 | US |
| 9550404 | 2016-03-21 | 12 | US |
| 9550404 | 2014-01-17 | 1 | us |
| 1630-00-847-3731 | 2013-01-10 | 5 | US |
| 9550404 | 2011-09-09 | 3 | United States |
| 9550404 | 2010-09-16 | 5 | United States |
| 9550404 | 2010-09-09 | 1 | United States |
| 1630-00-847-3731 | 2009-07-01 | 2 | Australia |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 1630-00-847-3731
1630-00-847-3763, 1630-00-849-3152, 1630-00-850-1917, 1630-00-851-9086, 1630-00-851-9095
Technical Data | NSN 1630-00-847-3731
| Characteristic | Specifications |
|---|---|
| OPERATION METHOD | HYDRAULIC |
| ROTATING DISK OUTSIDE DIAMETER | 9.000 INCHES NOMINAL |
| ROTATING DISK THICKNESS | 0.288 INCHES NOMINAL |
| STATIONARY DISK THICKNESS | 0.281 INCHES NOMINAL |
| ROTATING DISK QUANTITY | 2 |
| INSTALLATION LOCATION | LEFT HAND SIDE OR RIGHT HAND SIDE |
| OVERALL DIAMETER | 10.750 INCHES NOMINAL |
| OVERALL WIDTH | 3.500 INCHES NOMINAL |
| WHEEL SIZE FOR WHICH DESIGNED | 7 BY 8 IN. |
| III FSC APPLICATION DATA | WHEEL,ACFT LANDING GEAR |
| MANUFACTURERS CODE | 0B9R9 |
| DESIGN CONTROL REFERENCE | 9550404 |
Restrictions/Controls & Freight Information | NSN 1630-00-847-3731
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | B | Munitions List Item - Mutilation (MUT) to the point of scrap required. (Formerly: Demilitarization not required. Trade Security Controls (TSCs) required at disposition.) |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 011920 | AIRCRAFT BRAKES R PARTS NOI |
| Less than car load rating | ||
| Less than truck load rating | J | 100.2 |
| Water commodity Code | 671 | unknown |
| Originating Activity Code | SU | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | ||
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 1630-00-847-3731
Air Force| Category | Code | Description |
|---|---|---|
| Budget Code | C | 1857X3010:Procurement Other than Air Force |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | VU | Vendor to user-of-supply concept. |
| Materiel Management Aggregation Code | XW | SU:FMS UNIQUE/SA-ALC |
| Source of Supply | F4U | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | T | AF Recoverable Assembly Management System (AFRAMS) |
| Acquisition Advice Codes | P | RESTRICTED REQUISITION - SECURITY ASSISTANCE PROGRAM (SAP) 1. Indicates item is stocked or acquired only for SAP (replaces Military Assistance Program (MAP)) requirements, or 2. Indicates item is nonstocked and materiel is ordered from the contractor for shipment directly to the foreign government. 3. Base, post, camp, or station will not requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
