NSN 2040-00-129-6483 H115952, H11595-2, 11595PC2
Product Details | DECK VENTILATOR
2040-00-129-6483 A device fabricated of sheet or cast metal, consisting of an air scoop or a hood with provisions for mounting on the deck of a boat or ship to provide ventilation for the inclosed space below. The hood or head may have either an integral mounting flange or a separable base.
Part Alternates: H115952, H11595-2, 11595PC2, 11662PC21, 2040-00-129-6483, 00-129-6483, 2040001296483, 001296483
Ship and Marine Equipment | Marine Hardware and Hull Items
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 20 | 11 DEC 1968 | 00-129-6483 | 13122 ( VENTILATOR, DECK ) |
Drawings & Photos | NSN 2040-00-129-6483
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2040-00-129-6483
Technical Data | NSN 2040-00-129-6483
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM |
| STYLE DESIGNATOR | A1 COWL FLANGE TYPE |
| OVERALL HEIGHT | 11.750 INCHES NOMINAL |
| BOTTOM OPENING SHAPE | RECTANGULAR |
| INSIDE LENGTH | 4.000 INCHES NOMINAL |
| INSIDE WIDTH | 2.500 INCHES NOMINAL |
| MOUTH OPENING SHAPE | RECTANGULAR |
| MOUTH OPENING INSIDE WIDTH | 2.625 INCHES NOMINAL |
| MOUTH OPENING INSIDE HEIGHT | 4.000 INCHES NOMINAL |
| INTEGRAL MOUNTING BASE | INCLUDED |
| OUTSIDE DIAMETER | 4.250 INCHES NOMINAL |
| WIDTH | 4.250 INCHES NOMINAL |
| LENGTH | 6.000 INCHES NOMINAL |
| VENTILATOR TYPE | FIXED POSITION |
| DECK PLATE | NOT INCLUDED |
| VENTILATION CLOSING DEVICE | NOT INCLUDED |
| WATERPROOF FEATURE | INCLUDED |
| INSECTPROOF FEATURE | NOT INCLUDED |
| MANUFACTURERS CODE | 07070 |
| DESIGN CONTROL REFERENCE | 11595PC2 |
Restrictions/Controls & Freight Information | NSN 2040-00-129-6483
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 024740 | BOAT COWLS/VENTILATORS |
| Less than car load rating | ||
| Less than truck load rating | D | 200.0 |
| Water commodity Code | 810 | unknown |
| Originating Activity Code | HD | Naval Inventory Control Point Mechanicsburg, PA 17055-0788 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | R | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2040-00-129-6483
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
