NSN 2320-00-788-9876 8736682, M601, 00-788-9876

Product Details | CARGO TRUCK


2320-00-788-9876 A truck with either a box type body or a body having integral sides and front panel mounted on a chassis or articulated unit. It usually consists of a flat loading platform, tailgate, removable top bows, and tarpaulin. It may include side extensions or stakes. The rear wheels may be powered by a chain, an electric, hydraulic, and/or air motor(s), or conventional drive.20223200034Trucks and Truck Tractors, Wheeled23550047Combat, Assault, and Tactical Vehicles, Wheeled

Part Alternates: 8736682, M601, 2320-00-788-9876, 00-788-9876, 2320007889876, 007889876

Ground Effect Vehicles, Motor Vehicles, Trailers, and Cycles | Trucks and Truck Tractors, Wheeled

Supply Group (FSG) NSN Assign. NIIN
23 01 JAN 1960 00-788-9876

Drawings & Photos | NSN 2320-00-788-9876




Cross Reference | NSN 2320-00-788-9876


Part Number Cage Code Manufacturer
8736682 19207 U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM
M601 19207 U S ARMY TANK AUTOMOTIVE COMMAND AMSTA-IM-MM

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 2320-00-788-9876


Technical Data | NSN 2320-00-788-9876


Characteristic Specifications
RATED LOAD CAPACITY 1.00 TONS
WHEEL QUANTITY 4
DRIVE WHEEL QUANTITY 4
DRIVE AXLE LOCATION FRONT AND REAR
AXLE DRIVE TYPE CONVENTIONAL
AXLE SPEED QUANTITY 1
FRONT AXLE ENGAGING MECHANISM TYPE MANUAL
REAR WHEEL MOUNTING TYPE SINGLE
NOMINAL WHEELBASE 126.00 INCHES
FRONT WHEEL TREAD NOMINAL WIDTH 64.75 INCHES
REAR WHEEL TREAD NOMINAL WIDTH 64.75 INCHES
PRIME MOVER TYPE GASOLINE ENGINE
CYLINDER QUANTITY 6
ENGINE BRAKE HORSEPOWER 94.0
ENGINE HORSEPOWER RATING SPEED IN RPM 3200.0
TRANSMISSION TYPE MANUAL
FORWARD SPEED QUANTITY 4
REVERSE SPEED QUANTITY 1
TRANSMISSION ADJUNCT TYPE TRANSFER
TRANSMISSION ADJUNCT SPEED QUANTITY 2
WINCH LOCATION FRONT
WINCH TYPE SINGLE DRUM
GYPSY HEAD NOT INCLUDED
MAXIMUM LOAD RATING 8800.0 POUNDS
SEATING CAPACITY 2
CAB TYPE CONVENTIONAL
CAB DOOR QUANTITY ANY ACCEPTABLE
CAB ROOF TYPE OPEN
BATTERY QUANTITY ANY ACCEPTABLE
BATTERY VOLTAGE RATING IN VOLTS 12.0
BRAKE ACTUATION METHOD HYDRAULIC AND VACUUM
FEATURES PROVIDED TAILGATE
HINGE LOCATION BOTTOM
TAILGATE OPERATION METHOD MANUAL
BODY MATERIAL STEEL AND WOOD
CARGO AREA NOMINAL LENGTH 96.00 INCHES
CARGO AREA NOMINAL WIDTH 54.00 INCHES
CARGO AREA NOMINAL HEIGHT 20.00 INCHES
REFERENCE NUMBER DIFFERENTIATING CHARACTERISTICS AS DIFFERENTIATED BY REPLY TO ITEM NAME AND PAC CNWB
MANUFACTURERS CODE 19207
DESIGN CONTROL REFERENCE 8736682

Restrictions/Controls & Freight Information | NSN 2320-00-788-9876


Category Code Description
Hazardous Material Indicator CodeNThere is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials
Demilitarization Code:ANon-Munitions List Item/ Non-Strategic List Item - Demilitarization not required.
Precious Metals Indicator Code:UPrecious metal type is unknown
Criticality Code:X The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application.
Category Code Description
NMF Description 190190 VEHICLE MTR:AUTO FRT NOI TRACTORS
Less than car load rating F 150
Less than truck load rating F 150.0
Water commodity Code 867 unknown
Originating Activity Code XX
Air Dimension Code Z Shipment is not a consolidation, but does exceed 72 inches in one or more dimensions.
Air Commodity V Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above.
Air Special Handling Z No special handling required.
Special Handling Code R unknonwn
HAZMAT
Type of Cargo Z No special type of cargo code applicable
