NSN 2530-00-080-6791 20141, 35-9236136, 9236136
Product Details | PNEUMATIC TIRE WHEEL
2530-00-080-6791 A wheel with an integral or removable rim designed to mount a pneumatic tire. Includes wheels without rims but designed to accommodate pneumatic tire rims. May include tire(s). Excludes WHEEL, LANDING GEAR.202253000002610000000
Part Alternates: 20141, 35-9236136, 9236136, 2530-00-080-6791, 00-080-6791, 2530000806791, 000806791, 359236136
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 08 DEC 1967 | 00-080-6791 | 17959 ( WHEEL, PNEUMATIC TIRE ) |
Drawings & Photos | NSN 2530-00-080-6791
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 2530-00-080-6791
Technical Data | NSN 2530-00-080-6791
| Characteristic | Specifications |
|---|---|
| TIRE RIM NOMINAL DIAMETER | 25.000 INCHES |
| TIRE | NOT INCLUDED |
| DESIGN FORM | DISK |
| DISK TYPE | SINGLE |
| MOUNTING FACE TYPE | CENTERED |
| LIGHTENING HOLE | NOT INCLUDED |
| DESIGN TYPE | INTEGRAL RIM |
| RIM STYLE | 25 |
| GROOVE DEPTH | 1.812 INCHES NOMINAL |
| OVERALL WIDTH | 17.500 INCHES NOMINAL |
| EFFECTIVE WIDTH | 14.000 INCHES NOMINAL |
| METAL THICKNESS | 0.313 INCHES NOMINAL |
| RING TYPE FOR WHICH DESIGNED | SIDE |
| RING | NOT INCLUDED |
| RING STYLE | D7 RIM SIDE RING CURVED |
| BOLT/STUD MOUNTING FACILITY | NOT INCLUDED |
| VALVE HOLE SHAPE | ROUND |
| HOLE LOCATION | LOCATED BETWEEN CENTER AND OUTSIDE OF RIM |
| MOUNTING TYPE FOR WHICH DESIGNED | SINGLE TIRE |
| HUB CHARACTERISTIC | DEMOUNTABLE |
| HUB | NOT INCLUDED |
| BEARINGS | NOT INCLUDED |
| PILOT HOLE DIAMETER | 17.625 INCHES MINIMUM AND 17.635 INCHES MAXIMUM |
| MOUNTING HOLE QUANTITY | 10 |
| MOUNTING HOLE DIAMETER | 0.781 INCHES NOMINAL |
| MOUNTING BOLT CIRCLE DIAMETER | 19.495 INCHES MINIMUM AND 19.505 INCHES MAXIMUM |
Restrictions/Controls & Freight Information | NSN 2530-00-080-6791
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 197592 | WHEELS NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
