Product Details | WHEEL HYDRAULIC BRAKE CYLINDER ASSEMBLY
2530-00-391-3968 A device consisting of a CYLINDER, HYDRAULIC BRAKE, WHEEL with a piston(s) and other component parts which is mounted to the back plate of a wheel. It uses the flow and pressure of a fluid to create the linear motion required to operate the brake shoes of a hydraulic brake system.20216300032Aircraft Wheel and Brake Systems25300060Vehicular Brake, Steering, Axle, Wheel, and Track Components
Part Alternates: NU14494, H14494, H-14494, W14494, WC14494, EW14494, F14494, FD14494, 14494, 17282, 172-82, 2959, 3537, 543817, 5455478, 5456420, 5461125, 2530-00-391-3968, 00-391-3968, 2530003913968, 003913968
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 01 JAN 1963 | 00-391-3968 | 10862 ( CYLINDER ASSEMBLY, HYDRAULIC BRAKE, WHEEL ) |
Drawings & Photos | NSN 2530-00-391-3968
Cross Reference | NSN 2530-00-391-3968
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 14494 | 19239 | ECHLIN INC |
| 172-82 | 76462 | DELCO MORAINE DIV OF GENERAL MOTORS CORP |
| 2959 | 41340 | MONTGOMERY WARD AND CO INC |
| 3537 | 06840 | BENDIX CORP THE |
| 3537 | 14892 | BENDIX CORP THE BRAKE AND STEERING DIV |
| 543817 | 23862 | MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP |
| 5455478 | 23862 | MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP |
| 5455478 | 7X677 | GENERAL MOTORS LLC DBA GENERAL MOTORS |
| 5456420 | 23862 | MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP |
| 5461125 | 23862 | MILITARY VEHICLES OPN GENERAL MOTORS TRUCK AND BUS GROUP |
| 5461125 | 7X677 | GENERAL MOTORS LLC DBA GENERAL MOTORS |
| EW14494 | 80724 | EIS BRAKE PARTS DIV OF STANDARD MOTOR PRODUCTS INC |
| F14494 | 63477 | FEDERAL MOGUL CORP SUB WAGNER BRAKE |
| FD14494 | 63477 | FEDERAL MOGUL CORP SUB WAGNER BRAKE |
| H-14494 | 86403 | CHRYSLER CORP SERVICE AND PARTS OPNS |
| NU14494 | 34558 | BRAKE PARTS CO SUB OF THE ECHLIN MFG CO |
| W14494 | 71425 | AIRTEX PRODUCTS DIV OF UIS INC |
| WC14494 | 66614 | TRW INC REPLACEMENT PARTS DIV |
| WC14494 | 76761 | C. E. NIEHOFF & CO. |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 2530-00-391-3968
Related Products | NSN 2530-00-391-3968
2530-00-391-3969, 2530-00-391-3973, 2530-00-391-3976, 2530-00-391-3977, 2530-00-391-3979
Technical Data | NSN 2530-00-391-3968
| Characteristic | Specifications |
|---|---|
| DESIGN CHARACTERISTICS | DOUBLE ACTING SINGLE CYLINDER |
| OVERALL WIDTH | 2.625 INCHES NOMINAL |
| OVERALL HEIGHT | 1.812 INCHES NOMINAL |
| BODY OUTSIDE DIAMETER | 1.625 INCHES NOMINAL |
| BODY MATERIAL | IRON, CAST |
| BORE TYPE | STRAIGHT |
| BORE DIAMETER | 1.125 INCHES NOMINAL |
| (NON-CORE DATA) FIRST PISTON ROD END LUBRICATION FACILITY | NOT INCLUDED |
| (NON-CORE DATA) SECOND PISTON ROD END LUBRICATION FACILITY | NOT INCLUDED |
| MOUNTING TYPE AND LOCATION | FLANGE CENTER SECTION |
| MOUNTING PROVISION | THREADED MOUNTING HOLES |
| MOUNTING PROVISION ARRANGEMENT STYLE | 1 TWO HOLE |
| CENTER TO CENTER DISTANCE BETWEEN MOUNTING PROVISIONS | 1.625 INCHES NOMINAL |
| MOUNTING FACILITY THREAD SERIES DESIGNATOR | UNC |
| MOUNTING FACILITY THREAD DIAMETER | 0.312 INCHES NOMINAL |
| MOUNTING FACILITY THREAD QUANTITY PER INCH | 18 |
| MOUNTING FACILITY THREAD CLASS | 2B |
| MOUNTING FACILITY THREAD DIRECTION | RIGHT-HAND |
| MOUNTING FACILITY THREAD LENGTH | 0.344 INCHES NOMINAL |
| PORT LOCATION AND QUANTITY | 1 CENTER SECTION |
| PORT STYLE | 5 GASKET SEAL |
| PORT THREAD SERIES DESIGNATOR | UNF |
| PORT THREAD DIAMETER | 0.438 INCHES NOMINAL |
| PORT THREAD QUANTITY PER INCH | 20 |
| PORT THREAD CLASS | 2B |
| TEMP RATING | NOT RATED |
| MOUNTING POSITION | RIGHT |
| BLEEDING FEATURE QUANTITY | 1 |
| FEATURES PROVIDED | RUBBER BOOT |
Restrictions/Controls & Freight Information | NSN 2530-00-391-3968
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 133300 | MACHINERY/MACHINES NOI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2530-00-391-3968
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9C | Navy-owned stocks of defense construction material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9C | Defense Supply Center Columbus Columbus, OH 43215 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative | Purchasing | QTY UOM |
1 EA : Each |
