Product Details | STEERING GEAR ARM
2530-01-457-9916 The portion of a steering mechanism that connects the sector shaft to the tie rod(s) or drag link.
Part Alternates: NW34208, 0660297, 06-60297, 2530-01-457-9916, 01-457-9916, 2530014579916, 014579916
Vehicular Equipment Components | Vehicular Brake, Steering, Axle, Wheel, and Track Components
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 25 | 10 AUG 1998 | 01-457-9916 | 10854 ( ARM, STEERING GEAR ) |
Drawings & Photos | NSN 2530-01-457-9916
Demand History | NSN 2530-01-457-9916
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 06-60297 | 2021-11-29 | 1 | DIBBS |
| NW34208 | 2021-11-29 | 1 | DIBBS |
| 06-60297 | 2021-08-03 | 2 | DIBBS |
| NW34208 | 2021-08-03 | 2 | DIBBS |
| 2530-01-457-9916 | 2018-11-20 | 22 | DIBBS |
| 2530-01-457-9916 | 2018-04-26 | 1 | DIBBS |
| 2530-01-457-9916 | 2018-03-29 | 1 | DIBBS |
| 0660297 | 2016-09-09 | 1 | Thailand |
| 2530-01-457-9916 | 2010-03-17 | 15 | DIBBS |
| 2530-01-457-9916 | 2007-04-23 | 25 | DIBBS |
| 2530-01-457-9916 | 2006-03-14 | 28 | DIBBS |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 2530-01-457-9916
Related Products | NSN 2530-01-457-9916
2530-01-458-0119, 2530-01-458-0260, 2530-01-458-0263, 2530-01-458-1267, 2530-01-458-1273
Technical Data | NSN 2530-01-457-9916
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | STRAIGHT |
| CENTER TO CENTER DISTANCE BETWEEN BALL/BALL STUD HOLE AND SECTOR SHAFT BORE | 2.500 INCHES NOMINAL |
| SECTOR SHAFT MOUNTING END OVERALL WIDTH | 0.750 INCHES NOMINAL |
| SECTOR SHAFT MOUNTING END OVERALL THICKNESS | 0.672 INCHES NOMINAL |
| SECTOR SHAFT MOUNTING END SERRATED BORE | NOT INCLUDED |
| DRAG LINK END CHARACTERISTIC | W/BALL STUD BORE |
| BORE SMALLEST DIAMETER | 0.560 INCHES NOMINAL |
| BORE LENGTH | 0.810 INCHES NOMINAL |
Restrictions/Controls & Freight Information | NSN 2530-01-457-9916
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | P | There is no information in the HMIS; however, the NSN is in an FSC in Table II of Federal Standard 313 and an MSDS may be required by the user. The requirement for an MSDS is dependent on a hazard determination of the supplier or the intended end use of the product |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 019640 | AUTO STEERING ARMS STEEL |
| Less than car load rating | ||
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 885 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
