NSN 2910-00-175-9541 M4386, M4386SB, 9L6231
Product Details | CAM ACTUATED FUEL PUMP
2910-00-175-9541 A device designed to transfer liquid fuel from a tank to a carburetor, or fuel injector metering and distribution pump of an internal combustion engine. Reciprocating motion of the diaphragm(s) is actuated through linkage from the engine camshaft. It may include a diaphragm actuated vacuum booster. Excludes electrical and rotor type engine fuel pumps.20229100042Engine Fuel System Components, Nonaircraft29150064Engine Fuel System Components, Aircraft and Missile Prime Movers
Part Alternates: M4386, M4386SB, 9L6231, 9L7180, 2910-00-175-9541, 00-175-9541, 2910001759541, 001759541
Engine Accessories | Engine Fuel System Components, Nonaircraft
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 17 DEC 1971 | 00-175-9541 | 22184 ( PUMP, FUEL, CAM ACTUATED ) |
Demand History | NSN 2910-00-175-9541
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2910-00-175-9541 | 2025-09-252 | 2 | NL |
| 9L7180 | 2013-09-260 | 1 | US |
| 2910-00-175-9541 | 2011-11-315 | 1 | US |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2910-00-175-9541
Related Products | NSN 2910-00-175-9541
Technical Data | NSN 2910-00-175-9541
| Characteristic | Specifications |
|---|---|
| VACUUM BOOSTER | NOT INCLUDED |
| FUEL FILTER | NOT INCLUDED |
| ACTUATION METHOD | DIRECT CAM |
| STROKE LENGTH | 0.250 INCHES NOMINAL |
| PRIMING LEVER | INCLUDED |
| OVERALL LENGTH | 5.500 INCHES NOMINAL |
| OVERALL WIDTH | 3.250 INCHES NOMINAL |
| OVERALL HEIGHT | 4.625 INCHES NOMINAL |
| MOUNTING TYPE | NONSTANDARD |
| DISTANCE FROM PUMP MOUNTING FACE TO ACTUATOR CENTER | 2.202 IN. TO CENTERLINE OF CAM |
| INLET CONNECTION TYPE/SIZE | FUEL 0.125 IN. PIPE SIZE |
| OUTLET CONNECTION TYPE/SIZE | FUEL 0.125 IN. PIPE SIZE |
| FORDING FEATURE | NOT INCLUDED |
| DRAIN FACILITY | NOT INCLUDED |
| FURNISHED ITEMS AND QUANTITY | GASKET 1 |
Restrictions/Controls & Freight Information | NSN 2910-00-175-9541
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 127600 | PUMPS CIRC/FUEL I/C ENG |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2910-00-175-9541
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SU | SU:AF SICA RESIDUAL MMAC-OO-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | J | NOT STOCKED, CENTRALLY PROCURED # (NON-STOCKED ITEMS) IMM/Service centrally managed but not stocked item. Procurement will be initiated only after receipt of a requisition. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
