NSN 2910-00-676-4957 M20000306, M20000-306, A72841
Product Details | ELECTRICAL FUEL PUMP
2910-00-676-4957 An electrically actuated positive displacement device, which utilizes reciprocating or rotary motion to transfer fuel from a tank to a carburetor or fuel injector metering and distribution pump of an internal combustion engine. Excludes General Purpose Pumps.
Part Alternates: M20000306, M20000-306, A72841, A7284-1, C4796G15, EN1512, EN-15-12, JHP85151, JHP85-151, 00323-0036, 113849, 157E152186, 157E15-2186, 20000306, 20000-306, 3230036, 323-0036, 328AS4021, 328AS402-1, 47628424VN, 476284-24VN, 476284E, 6050, 65188, 2910-00-676-4957, 00-676-4957, 2910006764957, 003230036, 006764957
Engine Accessories | Engine Fuel System Components, Nonaircraft
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 29 | 01 JAN 1961 | 00-676-4957 | 32701 ( PUMP, FUEL, ELECTRICAL ) |
Drawings & Photos | NSN 2910-00-676-4957
Demand History | NSN 2910-00-676-4957
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 2910-00-676-4957 | 2023-11-319 | 5 | United States |
| 6050 | 2016-03-81 | 4 | United States |
| 476284E | 2014-06-169 | 6 | US |
| 476284E | 2012-05-143 | 1 | US |
| 2910-00-676-4957 | 2011-05-137 | 1 | United States |
| 476284E | 2007-12-344 | 1 | US |
Cross Reference | NSN 2910-00-676-4957
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 00323-0036 | 79343 | SCIENCE APPLICATIONS INTERNATIONAL CORPORATION |
| 00323-0036 | 93568 | HARSCO CORP BMY-COMBAT SYSTEMS DIV |
| 113849 | 15434 | CUMMINS INC. |
| 157E15-2186 | 75377 | KURZ & ROOT GENERATOR COMPANY LLC |
| 20000-306 | 54764 | MANCRAFT INDUSTRIES INC |
| 323-0036 | 93568 | HARSCO CORP BMY-COMBAT SYSTEMS DIV |
| 328AS402-1 | 30003 | NAVAL AIR SYSTEMS COMMAND |
| 476284-24VN | 72850 | PUROLATOR PRODUCTS CO DIV MOTOR COMPONENTS LLC |
| 476284E | 70898 | BEECHCRAFT CORPORATION DBA HAWKER BEECHCRAFT |
| 6050 | 06504 | WALBRO ENGINE MANAGEMENT |
| 65188 | 93742 | ENGINEERED ELECTRIC COMPANY DBA DRS FERMONT |
| A7284-1 | 93742 | ENGINEERED ELECTRIC COMPANY DBA DRS FERMONT |
| C4796G15 | 46522 | DCM MANUFACTURING INC. |
| EN-15-12 | 0CSK6 | WINCO, INC. |
| EN-15-12 | 77260 | PIERCE CO INC THE SUB OF AVIS INDUSTRIAL CORP |
| JHP85-151 | 02032 | HOLLINGSWORTH JOHN R CO |
| M20000-306 | 54764 | MANCRAFT INDUSTRIES INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 2910-00-676-4957
Related Products | NSN 2910-00-676-4957
Technical Data | NSN 2910-00-676-4957
| Characteristic | Specifications |
|---|---|
| VACUUM BOOSTER | NOT INCLUDED |
| FUEL FILTER | INCLUDED |
| FUEL FILTER LOCATION | BOTTOM |
| VOLTAGE IN VOLTS | 24.0 |
| GROUND POLARITY TYPE | NEGATIVE |
| OVERALL LENGTH | 5.250 INCHES NOMINAL |
| MOUNTING HOLE QUANTITY | 2 |
| MOUNTING HOLE SIZE | 0.250 IN. X 0.375 IN. |
| MOUNTING HOLE SPACING | DIAGONALLY SPACED ON 2.500 IN. C TO C |
| INLET CONNECTION TYPE/SIZE | FUEL 0.125-27 NPT,CL 2B,RH FEMALE |
| OUTLET CONNECTION TYPE/SIZE | FUEL 0.125-27 NPT,CL 2B,RH FEMALE |
Restrictions/Controls & Freight Information | NSN 2910-00-676-4957
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | J | PILFERAGE - PILFERAGE CONTROLS MAY BE DESIGNATED BY THE CODING ACTIVITY TO ITEMS CODED U (UNCLASSIFIED) BY RECORDING THE ITEM TO J./  |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 127600 | PUMPS CIRC/FUEL I/C ENG |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 2910-00-676-4957
Army
Air Force
Navy
Marines| Category | Code | Description |
|---|---|---|
| Materiel Category and Inventory Manager | J | Ground Forces Support Materiel (DLA/GSA Items) |
| Appropriation and Budget Activity | 2 | Stock Fund Secondary Items |
| Management Inventory Segment | 2 | NONREPARABLE ITEMS (Exclusive of Insurance and Provisioning Items). This code will be used to identify items which are not reparable. |
| Specific Group/Generic Code | 0 | Medical Materiel |
| Weapons Systems/End Item or Homogeneous Group | 00 | DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item |
| Accounting Requirements Code | X | Expendable item. An item of Army property coded with an ARC of ?X? in the AMDF. Expendable items require no formal accountability after issue from a stock record account. Commercial and fabricated items similar to items coded ?X? in the AMDF are considered expendable items. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DA | Department of the Army |
| Service Organization | A | U.S. Army |
| Reparability | Z | This is a nonreparable item. If condemned or economically unserviceable, then dispose at the level authorized replace the item. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | J | PILFERAGE - PILFERAGE CONTROLS MAY BE DESIGNATED BY THE CODING ACTIVITY TO ITEMS CODED U (UNCLASSIFIED) BY RECORDING THE ITEM TO J. |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SU | SU:AF SICA RESIDUAL MMAC-OO-ALC |
| Price Validation | V | The current standard price has been validated.
|
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | J | PILFERAGE - PILFERAGE CONTROLS MAY BE DESIGNATED BY THE CODING ACTIVITY TO ITEMS CODED U (UNCLASSIFIED) BY RECORDING THE ITEM TO J. |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Stores Account Code | 1 | Marine Corps Stock Fund Account Item. |
| Combat Essentiality Code | 5 | Critical Repair Part to a Combat Essential End Item. Those parts or components whose failure in a combat essential end item will render the end item inoperative or reduce its effectiveness below the minimum acceptable level of efficiency. |
| Materiel Management Code | B | All CommoditiesDefense Logistics Agency, (DLA,) |
| Echelon Management Code | 2 | ICP/DSSC Marine Corps-managed Recoverability Code D items and Defense Logistics Agency (DLA)/TACOM/GSA) items which the integrated manager has not decontrolled. |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DM | U.S. Marine Corps |
| Service Organization | M | U.S. Marine Corps |
| Reparability | Z | Nonreparable item. When unserviceable, condemn and dispose at the level indicated by the first digit of the maintenance code. |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | J | PILFERAGE - PILFERAGE CONTROLS MAY BE DESIGNATED BY THE CODING ACTIVITY TO ITEMS CODED U (UNCLASSIFIED) BY RECORDING THE ITEM TO J. |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Reparability | D | Field Level Reparables |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | J | PILFERAGE - PILFERAGE CONTROLS MAY BE DESIGNATED BY THE CODING ACTIVITY TO ITEMS CODED U (UNCLASSIFIED) BY RECORDING THE ITEM TO J. |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
