NSN 3040-01-285-0749 EAA870090U, EAA-8700-90U, EAA8700U
Product Details | LINEAR ACTUATING CYLINDER ASSEMBLY
3040-01-285-0749 A cylinder containing a piston and other component parts designed to develop linear motion required to operate a given object(s) with energy generated from either pneumatic or hydraulic pressure(s). See also CYLINDER, ACTUATING, LINEAR. Do not use if a more specific name applies.2041045000011900057Specialized Test and Handling Equipment, Nuclear Ordnance16500058Aircraft Hydraulic, Vacuum, and De-icing System Components30400042Miscellaneous Power Transmission Equipment
Part Alternates: EAA870090U, EAA-8700-90U, EAA8700U, EAA-8700-U, 187245A258, 1872-45A258, 2226090, 2AH471, 45A258, 3040-01-285-0749, 01-285-0749, 3040012850749, 012850749
