NSN 3110-01-311-9734 95AD791D, 95-AD-791D, 01-311-9734
Product Details | CYLINDRICAL ROLLER BEARING
3110-01-311-9734 A nonadjustable roller bearing consisting of a single or multiple-row of hardened cylindrical rollers and a retainer used with or without inner or oute r rings. Excludes BEARING, ROLLER, AIRFRAME.
Part Alternates: 95AD791D, 95-AD-791D, 3110-01-311-9734, 01-311-9734, 3110013119734, 013119734
Bearings | Bearings, Antifriction, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 07 DEC 1989 | 01-311-9734 | 00015 ( BEARING, ROLLER, CYLINDRICAL ) |
Drawings & Photos | NSN 3110-01-311-9734
Cross Reference | NSN 3110-01-311-9734
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 95-AD-791D | 02780 | AMERICAN ROLLER BEARING CO |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3110-01-311-9734
Technical Data | NSN 3110-01-311-9734
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL INNER RACE STEEL OUTER RACE |
| STYLE DESIGNATOR | 258D CYLINDRICAL INNER RING, TWO LIP OUTER RING W/CENTRAL ROLLER GUIDE, SEPARABLE |
| OVERALL WIDTH | 3.1250 INCHES NOMINAL |
| BORE DIAMETER | 9.5000 INCHES NOMINAL |
| OVERALL OUTSIDE DIAMETER | 15.1250 INCHES NOMINAL |
| BORE SHAPE | STRAIGHT |
| SURFACE FINISH | GROUND |
| LOCATING FEATURE | NONLOCATING |
| III END ITEM IDENTIFICATION | GEAR ASSEMBLY SPEED DECREASER PART NUMBER 01070-0269 ONBOARD 378 FT WHEC HULL NUMBER 715 COAST GUARD VESSELS |
| MANUFACTURERS CODE | 02780 |
| DESIGN CONTROL REFERENCE | 95-AD-791D |
Restrictions/Controls & Freight Information | NSN 3110-01-311-9734
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
Management | NSN 3110-01-311-9734
Coast Guard| Category | Code | Description |
|---|---|---|
| Inventory Account Codes | S | Stock Fund item managed for the Coast Guard by the respective Inventory Control Point. A funded requisition is required |
| Inventory Account Codes | 0 | Item not controlled by serial number. |
| Special Material Content Codes | 9 | Non-Hazardous or Non-Sensitive Item, does not require hazardous or special handling, packaging or precautions |
| Source of Supply | ZNC | Commanding Officer USCG Surface Force Logistics Center Code 028, Mil Stop 25 2401 Hawkins Point Road Baltimore, MD 21226-5000 |
| Agency | GP | U.S. Coast Guard |
| Service Organization | C | U.S. Coast Guard |
| Reparability | C | |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
