NSN 3120-00-180-7690 MS141038, MS14103-8 , MS212308
Product Details | SELF-ALIGNING PLAIN BEARING
3120-00-180-7690 A detachable assembly in or on which a journal, gudgeon, pivot, or the like moves. It is used to carry a load and to reduce sliding friction. It does not employ rolling elements. The item consists of a bored precision ground ball (or spherical plain bearing) around which an outer ring is fitted. The assembly may be either separable or nonseparable. Excludes BEARING, PLAIN, ROD END and BEARING, PLAIN, SPHERICAL.
Part Alternates: MS141038, MS14103-8 , MS212308, MS21230-8, SBSH16ATC32Z, SBSH16ATC32ZM, TGA108, LM303184, LM303-184, 3120-00-180-7690, 00-180-7690, 3120001807690, 001807690
Bearings | Bearings, Plain, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 08 JUL 1970 | 00-180-7690 | 13208 ( BEARING, PLAIN, SELF-ALIGNING ) |
Drawings & Photos | NSN 3120-00-180-7690
Demand History | NSN 3120-00-180-7690
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| MS141038 | 2025-09-255 | 10 | United States |
| MS141038 | 2024-01-02 | 50 | United States |
| 3120-00-180-7690 | 2020-09-274 | 1 | United States |
| MS14103-8 | 2020-08-227 | 31 | IN |
| MS141038 | 2020-06-163 | 20 | United States |
| MS141038 | 2020-04-107 | 6 | United States |
| MS212308 | 2018-07-212 | 27 | US |
| MS141038 | 2017-08-243 | 100 | Canada |
| MS141038 | 2017-08-243 | 200 | Canada |
| MS141038 | 2017-08-221 | 5 | United States |
| MS141038 | 2015-10-288 | 30 | Israel |
| MS141038 | 2015-04-113 | 1 | United States |
| MS141038 | 2014-02-48 | 30 | United States |
| MS141038 | 2013-09-260 | 11 | us |
| MS141038 | 2013-06-157 | 76 | US |
| MS212308 | 2012-11-326 | 10 | United States |
| MS141038 | 2012-04-101 | 2546 | United States |
| MS141038 | 2011-12-339 | 2 | US |
| MS141038 | 2011-12-339 | 5 | US |
| MS141038 | 2011-12-339 | 10 | US |
| MS141038 | 2011-10-291 | 65 | United States |
| 3120-00-180-7690 | 2011-07-200 | 110 | United States |
| MS141038 | 2011-04-105 | 3 | US |
| MS141038 | 2010-11-315 | 50 | United States |
| MS141038 | 2010-08-237 | 48 | US |
| MS141038 | 2010-08-225 | 8 | US |
| MS141038 | 2008-09-248 | 50 | US |
Cross Reference | NSN 3120-00-180-7690
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| LM303-184 | 76005 | LORD CORPORATION DBA AEROSPACE DIVISION |
| MS14103-8 | 15860 | NEW HAMPSHIRE BALL BEARINGS, INC. DBA ASTRO DIVISION |
| MS21230-8 | 96906 | MILITARY STANDARDS PROMULGATED BY MILITARY DEPARTMENTS |
| SBSH16ATC32Z | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| SBSH16ATC32Z | 3NPS1 | RBC AIRCRAFT PRODUCTS, INC. |
| SBSH16ATC32ZM | 21335 | TIMKEN COMPANY, THE DIV TIMKEN AEROSPACE |
| SBSH16ATC32ZM | 3NPS1 | RBC AIRCRAFT PRODUCTS, INC. |
| TGA108 | 77896 | REXNORD INDUSTRIES, LLC DIV BEARING OPERATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3120-00-180-7690
Related Products | NSN 3120-00-180-7690
Technical Data | NSN 3120-00-180-7690
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 440C INNER MEMBER STEEL COMP 410 AND STEEL COMP 630 AND STEEL COMP 631 OUTER RACE MEMBER |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 5630 ASSN STD SINGLE MATERIAL RESPONSE INNER MEMBER 66 FED STD 1ST MATERIAL RESPONSE AND AMS 5643 ASSN STD 2ND MATERIAL RESPONSE AND AMS 5528 ASSN STD 3RD MATERIAL RESPONSE OUTER RACE MEMBER |
| HARDNESS RATING | 55.0 ROCKWELL C MINIMUM AND 62.0 ROCKWELL C MAXIMUM INNER MEMBER 23.0 ROCKWELL C MINIMUM AND 35.0 ROCKWELL C MAXIMUM OUTER RACE MEMBER |
| STYLE DESIGNATOR | 10A WITH INSERT AND/OR LINER WITH STAKING GROOVE |
| BORE DIAMETER | 0.4995 INCHES MINIMUM AND 0.5000 INCHES MAXIMUM |
| OUTER MEMBER OUTSIDE DIAMETER | 0.9995 INCHES MINIMUM AND 1.0000 INCHES MAXIMUM |
| OUTER MEMBER WIDTH | 0.5000 INCHES MINIMUM AND 0.5100 INCHES MAXIMUM |
| INNER MEMBER WIDTH | 0.6230 INCHES MINIMUM AND 0.6250 INCHES MAXIMUM |
| STATIC RADIAL LOAD RATING | 27500 POUNDS |
| MANUFACTURERS CODE | 96906 |
| DEFINITIVE GOVERNMENT SPEC/STD REFERENCE | MS21230-8 |
Restrictions/Controls & Freight Information | NSN 3120-00-180-7690
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114850 | BEARING/BUSHING O/T BALL/ROLLER I/S |
| Less than car load rating | W | Rating Variable |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | KZ | Defense Supply Center Philadelphia Philadelphia, PA 19101 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Y | Protected cargo, other than above, including sensitive cargo requiring hand-to-hand receipt and/or security precautions. |
| Special Handling Code | 5 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3120-00-180-7690
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9Z | Navy-owned stocks of defense industrial material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | S9I | Defense Industrial Supply Center Philadelphia, PA 19111 |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
