NSN 3120-01-642-7767 MS141035P, MS14103-5P , 01-642-7767
Product Details | SELF-ALIGNING PLAIN BEARING
3120-01-642-7767 A detachable assembly in or on which a journal, gudgeon, pivot, or the like moves. It is used to carry a load and to reduce sliding friction. It does not employ rolling elements. The item consists of a bored precision ground ball (or spherical plain bearing) around which an outer ring is fitted. The assembly may be either separable or nonseparable. Excludes BEARING, PLAIN, ROD END and BEARING, PLAIN, SPHERICAL.
Part Alternates: MS141035P, MS14103-5P , 3120-01-642-7767, 01-642-7767, 3120016427767, 016427767
Bearings | Bearings, Plain, Unmounted
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 2015068 | 01-642-7767 | 13208 ( BEARING, PLAIN, SELF-ALIGNING ) |
Drawings & Photos | NSN 3120-01-642-7767
Demand History | NSN 3120-01-642-7767
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 3120-01-642-7767 | 2025-06-176 | 58 | DIBBS |
| 3120-01-642-7767 | 2023-03-81 | 17 | DIBBS |
| MS141035P | 2016-10-287 | 50 | US |
| 3120-01-642-7767 | 2016-02-56 | 20 | United States |
| MS141035P | 2015-02-56 | 25 | US |
| MS141035P | 2015-02-56 | 50 | US |
| MS141035P | 2015-02-56 | 75 | US |
| MS141035P | 2015-02-56 | 100 | US |
| MS141035P | 2015-02-56 | 150 | US |
| MS141035P | 2014-09-252 | 50 | United States |
| MS141035P | 2014-09-252 | 50 | United States |
| MS141035P | 2012-10-275 | 38 | US |
| MS141035P | 2011-08-214 | 500 | MY |
| MS141035P | 2006-12-338 | 110 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 3120-01-642-7767
Related Products | NSN 3120-01-642-7767
Technical Data | NSN 3120-01-642-7767
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL COMP 440C INNER MEMBER |
| HARDNESS RATING | 55.0 ROCKWELL C MINIMUM AND |
| SURFACE TREATMENT | CADMIUM OR |
| STYLE DESIGNATOR | WITH INSERT AND/OR LINER WITH STAKING GROOVE |
| BORE DIAMETER | 0.3120 INCHES MINIMUM AND |
| OUTER MEMBER OUTSIDE DIAMETER | 0.6870 INCHES MINIMUM AND |
| OUTER MEMBER WIDTH | 0.3120 INCHES MINIMUM AND |
| INNER MEMBER WIDTH | 0.4350 INCHES MINIMUM AND |
| STATIC RADIAL LOAD RATING | 9400 POUNDS |
| CRITICALITY CODE JUSTIFICATION | MATT AND |
Restrictions/Controls & Freight Information | NSN 3120-01-642-7767
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Electro-static Discharge Susceptible: | A | No known Electrostatic Discharge (ESD) or Electromagnetic Interference (EMI) sensitivity |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | Y | The item does not have a nuclear hardened feature but does have other critical feature(s) such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | TK | HQ AFMC/GLSC 401 SCM/GUMB Wright-Patterson AFB, OH 45433-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3120-01-642-7767
Air Force| Category | Code | Description |
|---|---|---|
| Materiel Management Aggregation Code | LE | SU:LANDING GEAR SYSTEMS AND COMPONENTS |
| Price Validation | P | The current standard price is the initial negotiated provisioned price.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Source of Supply | FGZ | Ogden Air Logistics Center Hill AFB, UT 84056-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | D | DoD INTEGRATED MATERIEL-MANAGED, STOCKED, AND ISSUED # Issue, transfer, or shipment is not subject to specialized controls other than those imposed by the Integrated Materiel Manager/Service supply policy. 1. The item is centrally managed, stocked, and issued. 2. Requisitions must contain the fund citation required to acquire the item. Requisitions will be submitted in accordance with Integrated Materiel Manager(IMM)/Service requisitioning procedures. |
| Controlled Item Code | V | INDIVIDUAL CLOTHING AND EQUIPMENT |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
