NSN 3130-00-056-2419 653047, 77A1532, 00-056-2419
Product Details | BEARING UNIT HOUSING
3130-00-056-2419 A single or multiple piece item without ball, plain or roller bearing(s). It is designed to meet various or specific conditions of mounting. For items with bearings, see BEARING UNIT, BALL; BEARING UNIT, PLAIN; and BEARING UNIT, ROLLER.
Part Alternates: 653047, 77A1532, 3130-00-056-2419, 00-056-2419, 3130000562419, 000562419
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 31 | 01 JAN 1963 | 00-056-2419 | 30559 ( HOUSING, BEARING UNIT ) |
Cross Reference | NSN 3130-00-056-2419
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 653047 | 0BR59 | DRESSER-RAND COMPANY DBA STEAM TRBINE MTR GENERATOR DIV |
| 653047 | 82328 | DRESSER RAND CO TERRY CORP STEAM TURBINE MOTOR AND |
| 77A1532 | 0BR59 | DRESSER-RAND COMPANY DBA STEAM TRBINE MTR GENERATOR DIV |
| 77A1532 | 82328 | DRESSER RAND CO TERRY CORP STEAM TURBINE MOTOR AND |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 3130-00-056-2419
Technical Data | NSN 3130-00-056-2419
| Characteristic | Specifications |
|---|---|
| BORE DIAMETER | 0.6693 INCHES NOMINAL |
| MATERIAL | COPPER ALLOY OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | SAE CA937 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| OVERALL OUTSIDE DIAMETER | 2.4980 INCHES MINIMUM AND 2.4990 INCHES MAXIMUM |
| HOUSING LENGTH | 2.5000 INCHES NOMINAL |
| SHAFT END TYPE | OPEN |
| MANUFACTURERS CODE | 0BR59 |
| DESIGN CONTROL REFERENCE | 653047 |
Restrictions/Controls & Freight Information | NSN 3130-00-056-2419
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 114820 | BEARINGS/BUSHINGS NOI BALL/ROLLER |
| Less than car load rating | ||
| Less than truck load rating | P | 77.5 |
| Water commodity Code | 742 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 3130-00-056-2419
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
