NSN 4520-01-073-8309 FC4002, FC400-2, 04100200
Product Details | PORTABLE DUCT TYPE HEATER
4520-01-073-8309 A heater equipped with integral connection(s) for attaching duct(s) to direct heat to engine surface, railroad cars, warehouses, tents, and the like. It is equipped with a blower (fan) and must be mounted on skids, wheels, and the like or capable of being hand-carried. Excludes HEATER, SPACE.
Part Alternates: FC4002, FC400-2, 04100200, 4520-01-073-8309, 01-073-8309, 4520010738309, 010738309
Plumbing, Heating, and Waste Disposal Equipment | Space and Water Heating Equipment
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 45 | 21 MAR 1979 | 01-073-8309 | 13028 ( HEATER, DUCT TYPE, PORTABLE ) |
Drawings & Photos | NSN 4520-01-073-8309
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4520-01-073-8309
Related Products | NSN 4520-01-073-8309
Technical Data | NSN 4520-01-073-8309
| Characteristic | Specifications |
|---|---|
| HEAT DELIVERY RATE | 400000.0 BRITISH THERMAL UNIT |
| HEATING ELEMENT TYPE | COMBUSTION CHAMBER |
| HEAT MEDIUM TYPE | AIR |
| FUEL FEED METHOD | INTERNAL PUMP |
| INTEGRAL FUEL TANK CAPACITY | 35.0 GALLONS |
| FUEL TYPE | JP-4 JET FUEL AND JP-5 JET FUEL AND DF-A ARCTIC DIESEL FUEL OIL AND DF-1 WINTER DIESEL FUEL OIL AND DF-2 REGULAR DIESEL FUEL OIL |
| IGNITION METHOD | ELECTRODE |
| MOUNTING TYPE | TRAILER |
| HEIGHT | 44.000 INCHES NOMINAL |
| WIDTH | 51.500 INCHES NOMINAL |
| DEPTH | 68.500 INCHES NOMINAL |
| HEAT OUTLET QUANTITY | 1 |
| HEAT DELIVERY DIRECTION | HORIZONTAL |
| HEAT DISCHARGE OUTLET TYPE | STATIONARY |
| HEAT DIRECTING DEVICE | FLEXIBLE DUCTS |
| AIR CIRCULATION DEVICE | PROPELLER FAN |
| QUANTITY | 1 |
| SPEED ADJUSTMENTS | SINGLE SPEED |
| MAXIMUM AIR FLOW RATE | 1500.0 CUBIC FEET PER MINUTE |
| PRIME MOVER TYPE | DIESEL ENGINE |
| CIRCULATED AIR TYPE | COOLING OR HEATED |
| OPERATING CONTROL TYPE | HAND SWITCH |
| SPECIAL FEATURES | 12 IN. DUCT,OR 12 IN. DUCT ADAP ASSY W/ 6 IN. DUCT ADAP FOR 3,6 IN. DUCTS OR,12 IN. DUCT W/ 6 IN. DUCT ADAP & 3,6 IN. DUCTS; UNSAFE IN EXP ATM;6 OPER TEMP; MAY BE USED INS BLDG WHEN EXHAUST GASSES ARE CONDUCTED TO OSD ATM VIA ADDL PIPES CONNECTED TO THE EXHAUST |
| III UNPACKAGED UNIT WEIGHT | 800.00 POUNDS |
| III FUNCTIONAL DESCRIPTION | BURNS DLS OR JET FUEL TO PREHEAT ACFT ENGINES & FUSELAGE OR HEAT GND VEHICLES,MAINT. BLDG,FLD SHELTER & TEMPORARY STRUCT. PROVIDES FORCED FRESH VENTILATION W/O HEATING |
| III REFERENCE DATA AND LITERATURE | TO. 35E7-2-11-11 |
| MANUFACTURERS CODE | 57386 |
| DESIGN CONTROL REFERENCE | FC400-2 |
Restrictions/Controls & Freight Information | NSN 4520-01-073-8309
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 062220 | HEATER, PORTABLE NOI SUB2 |
| Less than car load rating | P | 77.5 |
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 732 | unknown |
| Originating Activity Code | TG | Warner-Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | H | Signal Corps supplies and equipment, including radio equipment and supplies, communications equipment and supplies, electrical equipment and supplies, etc. |
| Air Special Handling | Q | Extremely fragile items including delicate instruments. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4520-01-073-8309
Air Force| Category | Code | Description |
|---|---|---|
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Budget Code | Y | variousO & M:AF centrally procured equipment items. They are separate, primary end items (other than the weapon system itself) needed by a user to perform an assigned mission. They are nonexpendable items (ERRCD NF or ND) which are not consumed in use, and they do not lose their original identity during periods of use by incorporation into, or attachment to another assembly. |
| Source of Supply | FLZ | Warner Robins Air Logistics Center Robins AFB, GA 31098-5609 |
| Agency | DF | Department of the Air Force |
| Service Organization | L | Lead Service - 22 (Repairable) |
| Reparability | S | AF Equipment Management System (AFEMS) |
| Acquisition Advice Codes | V | TERMINAL ITEM # Identifies items in stock, but future procurement is not authorized. Requisitions may continue to be submitted until stocks are exhausted. Preferred item National Stock Number is normally provided by application of the phrase: When Exhausted Use (NSN). Requisitions will be submitted in accordance with IMM/Service requisitioning procedures as applicable. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
