NSN 4710-00-598-9779 371353-437, 00-598-9779, 371353437
Product Details | METALLIC TUBE
4710-00-598-9779 A straight, hollow product, welded or seamless, of round, square, or any other cross section and continuous periphery, which does not conform in cross sectional dimensions to recognized pipe standards, or those in Tables 1 through 10, Appendix C, FIIG A004A. It is designed to convey fluids, gasses, and/or semisolids. It may be rolled into coils for ease in handling. For items designed to join a tube or tube fitting to another tube, pipe, or hose or fitting, see ADAPTER (as modified); COUPLING (as modified); or NIPPLE (as modified). Excludes TUBE, BENT (as modified); PIPE, METALLIC; SPACER, SLEEVE; METAL BAR (hollow); and items with fittings, except end protectors.
Part Alternates: 371353-437, 4710-00-598-9779, 00-598-9779, 4710005989779, 371353437, 005989779
Pipe, Tubing, Hose, and Fittings | Pipe, Tube and Rigid Tubing
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 16 JAN 1975 | 00-598-9779 | 31979 ( TUBE, METALLIC ) |
Drawings & Photos | NSN 4710-00-598-9779
Demand History | NSN 4710-00-598-9779
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4710-00-598-9779 | 2023-05-143 | 3 | Malaysia |
| 371353-437 | 2022-04-101 | 3 | DIBBS |
| 371353-437 | 2022-03-90 | 3 | DIBBS |
| 4710-00-598-9779 | 2021-07-209 | 1 | United States |
| 371353-437 | 2021-02-46 | 1 | DIBBS |
| 4710-00-598-9779 | 2017-12-344 | 2 | DIBBS |
| 4710-00-598-9779 | 2015-02-54 | 2 | DIBBS |
| 4710-00-598-9779 | 2015-02-41 | 2 | DIBBS |
| 4710-00-598-9779 | 2015-02-33 | 2 | DIBBS |
| 4710-00-598-9779 | 2015-01-19 | 2 | DIBBS |
| 4710-00-598-9779 | 2014-05-146 | 2 | DIBBS |
| 4710-00-598-9779 | 2014-03-85 | 2 | DIBBS |
| 4710-00-598-9779 | 2014-03-70 | 2 | DIBBS |
| 371353-437 | 2011-06-180 | 1 | US |
| 4710-00-598-9779 | 2010-06-175 | 10 | US |
| 4710-00-598-9779 | 2009-08-224 | 15 | DIBBS |
| 4710-00-598-9779 | 2009-06-160 | 8 | DIBBS |
| 4710-00-598-9779 | 2009-01-20 | 15 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4710-00-598-9779
Related Products | NSN 4710-00-598-9779
Technical Data | NSN 4710-00-598-9779
| Characteristic | Specifications |
|---|---|
| MEASURING METHOD AND LENGTH | 50.280 INCHES NOMINAL SPECIFIC |
| CROSS-SECTIONAL SHAPE STYLE | 1 PLAIN ROUND |
| WALL THICKNESS | 0.028 INCHES NOMINAL |
| DIAMETER | 3.000 INCHES NOMINAL |
| FIRST END STYLE | 14 OUTSIDE BEADED |
| FIRST END OUTSIDE DIAMETER | 3.000 INCHES NOMINAL |
| FIRST END BEAD OUTSIDE DIAMETER | 3.175 INCHES NOMINAL |
| FIRST END BEAD WIDTH | ANY ACCEPTABLE |
| FIRST END LENGTH FROM BEAD CENTER TO END | 0.220 INCHES MINIMUM AND 0.280 INCHES MAXIMUM |
| SECOND END RELATIONSHIP WITH FIRST END | IDENTICAL |
| CONSTRUCTION | SEAMLESS |
| MAXIMUM OPERATING PRESSURE | NOT RATED |
| MAXIMUM OPERATING TEMP | NOT RATED |
| HEAT TREATMENT | O-ANNEALED |
| MANUFACTURERS CODE | 98897 |
| DESIGN CONTROL REFERENCE | 371353-437 |
Restrictions/Controls & Freight Information | NSN 4710-00-598-9779
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051820 | PIPE R TUBING ALUM NOI |
| Less than car load rating | ||
| Less than truck load rating | M | 85.0 |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | SE | San Antonio Air Logistics Center Kelly AFB, TX 78241-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4710-00-598-9779
Air Force
Navy| Category | Code | Description |
|---|---|---|
| Budget Code | 9 | General Support DIV57X4921.070:Air Force decentrally managed expense items (ERRC XB3, XF-3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors. |
| Price Validation | N | The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
|
| Fund Code | SF | Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point. |
| Materiel Management Aggregation Code | SX | SX:AF SICA RESIDUAL MMAC-OC-ALC |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DF | Department of the Air Force |
| Service Organization | F | U.S. Air Force |
| Reparability | N | Stock Fund (except Munitions) |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
