NSN 4730-00-270-3901 T108436, 11963P11, 13229E0854
Product Details | INFLATING AIR CHUCK
4730-00-270-3901 An air hose fitting with a check valve, designed for adapting the discharge end of the hose to the mouth of the valve stems on inner tubes, pneumatic bags, tanks, and the like.
Part Alternates: T108436, 11963P11, 13229E0854, 14506, 150136, 150-136, 4X787, 5499, 6044, 699, 699BK, 4730-00-270-3901, 00-270-3901, 4730002703901, 002703901
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1961 | 00-270-3901 | 13593 ( CHUCK, AIR, INFLATING ) |
Drawings & Photos | NSN 4730-00-270-3901
Demand History | NSN 4730-00-270-3901
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5499 | 2022-08-221 | 1 | US |
| 6044 | 2021-12-344 | 2 | United States |
| 6044 | 2021-11-313 | 1 | United States |
| 4730-00-270-3901 | 2017-02-52 | 377 | DIBBS |
| 4730-00-270-3901 | 2016-12-356 | 407 | DIBBS |
| 4730-00-270-3901 | 2016-09-247 | 195 | DIBBS |
| 4730-00-270-3901 | 2016-03-87 | 195 | DIBBS |
| 4730-00-270-3901 | 2016-02-52 | 190 | DIBBS |
| 4730-00-270-3901 | 2013-06-171 | 1 | United States |
| 4730-00-270-3901 | 2011-06-161 | 545 | DIBBS |
Cross Reference | NSN 4730-00-270-3901
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 11963P11 | 27618 | TAYLOR MACHINE WORKS, INC. |
| 13229E0854 | 97403 | CECOM LR CENTER |
| 14506 | 16004 | DAVEY COMPRESSOR CO DIV OF KECO INDUSTRIES INC |
| 150-136 | 25980 | GRACO INC. |
| 4X787 | 25795 | W. W. GRAINGER, INC. DBA GRAINGER |
| 5499 | 13841 | TIFFIN PARTS, L.L.C. DIV SUBSIDIARY OF PETTIBONE CORP. |
| 5499 | 18702 | DUCOMMUN METALS CO |
| 5499 | 22852 | SPALLA INC |
| 5499 | 53477 | SCOVILL INC SCHRADER BELLOWS DIV |
| 6044 | 17875 | EATON CORPORATION DBA AIR CONTROLS DIVISION DIV AIR |
| 699 | 94894 | MILTON INDUSTRIES, INC. |
| 699BK | 94894 | MILTON INDUSTRIES, INC. |
| T108436 | 75755 | DEERE & COMPANY DBA JOHN DEERE |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-270-3901
Technical Data | NSN 4730-00-270-3901
| Characteristic | Specifications |
|---|---|
| DESIGN TYPE | SINGLE FOOT |
| SHANK TYPE | THREADED |
| THREAD LOCATION | INTERNAL |
| SCREW THREAD DIAMETER | 0.250 INCHES NOMINAL |
| SCREW THREAD SERIES DESIGNATOR | NPT |
| SPECIAL DEFLATOR | NOT INCLUDED |
| HOLDING CLIP | NOT INCLUDED |
| SPECIAL FEATURES | BRASS, NICKEL PLATED, 200 PSI WORKING PRESSURE |
| III END ITEM IDENTIFICATION | AIRCRAFT; B-52, PHANTOM F-4, STRATOLIFTER C-135, HERCULES C-130, DELTA DART F106, THUNDERBOLT II A-10; HELICOPTER H-3; WATER PURIFICATION UNIT, REVERSE OSMOSIS; TORPEDO, MARK 48 |
Restrictions/Controls & Freight Information | NSN 4730-00-270-3901
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 156600 | PLASTIC/RUBBER ARTICLE VIZ: |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 772 | unknown |
| Originating Activity Code | XX | |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
