NSN 4730-00-540-2096 B1622, B16-22, 00-540-2096
Product Details | TUBE ELBOW
4730-00-540-2096 A fitting that forms an angle of less than 180 degrees (3.141 radians) from a straight flow. Both connecting ends have machine threads (straight threads other than pipe or hose series) designed to accommodate a tube or is unthreaded and designed to accommodate a tube. It may have side or heel inlet(s). See also ELBOW, PIPE and CONNECTOR, MULTIPLE, FLUID PRESSURE LINE.
Part Alternates: B1622, B16-22, 4730-00-540-2096, 00-540-2096, 4730005402096, 005402096
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 01 JAN 1963 | 00-540-2096 | 03771 ( ELBOW, TUBE ) |
Demand History | NSN 4730-00-540-2096
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| B1622 | 2018-07-209 | 1 | |
| B1622 | 2018-06-177 | 2 | |
| B1622 | 2013-06-179 | 10 | |
| B1622 | 2013-03-67 | 5 | |
| B1622 | 2013-01-16 | 3 |
Cross Reference | NSN 4730-00-540-2096
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| B16-22 | 80204 | AMERICAN NATIONAL STANDARDS INSTITUTE, INCORPORATED |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-00-540-2096
Technical Data | NSN 4730-00-540-2096
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY OVERALL |
| CONNECTION TYPE | UNTHREADED INTERNAL TUBE 1ST END |
| CONNECTION STYLE | B30A SOCKET 1ST END |
| NOMINAL OUTSIDE DIAMETER TUBE ACCOMMODATED | 0.500 INCHES 1ST END |
| TUBING WALL NOMINAL THICKNESS FOR WHICH DESIGNED | 0.035 INCHES 1ST END |
| LEG LENGTH | 0.875 INCHES NOMINAL 1ST END |
| FLOW ANGLE | 90.0 DEGREES |
| DEPARTURE FROM CITED DOCUMENT | AS MODIFIED BY TUBING WALL THICKNESS FOR WHICH DESIGNED FROM FED STD 146 |
Restrictions/Controls & Freight Information | NSN 4730-00-540-2096
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
