NSN 4730-01-003-8860 W70164DE, W701-64DE, 12J7164AE
Product Details | FLEXIBLE TUBE COUPLING ASSEMBLY
4730-01-003-8860 A multipiece gasket sealed item specifically designed for joining plain end ferruled tubing or beaded end tubing that will accommodate angular misalignment, axial motion and permits expansion and contraction of the tubing. It may be disconnected for seal replacement without disturbing the rest of the line. The seals are not normally furnished with the item. For rigid type items see COUPLING, TUBE; and UNION, TUBE.
Part Alternates: W70164DE, W701-64DE, 12J7164AE, 12J71-64AE, 7D0256, 7D02561, 7D0256-1, W701, 4730-01-003-8860, 01-003-8860, 4730010038860, 010038860
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 12 MAY 1975 | 01-003-8860 | 32834 ( COUPLING ASSEMBLY, TUBE, FLEXIBLE ) |
Drawings & Photos | NSN 4730-01-003-8860
Demand History | NSN 4730-01-003-8860
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 12J71-64AE | 2019-01-13 | 12 | DIBBS |
| W701-64DE | 2019-01-13 | 12 | DIBBS |
| 4730-01-003-8860 | 2018-08-220 | 182 | US |
| 4730-01-003-8860 | 2018-08-218 | 182 | DIBBS |
| 4730-01-003-8860 | 2018-05-133 | 24 | DIBBS |
| 4730-01-003-8860 | 2017-09-247 | 51 | DIBBS |
| 4730-01-003-8860 | 2017-08-219 | 44 | DIBBS |
| 4730-01-003-8860 | 2017-02-37 | 10 | DIBBS |
| 4730-01-003-8860 | 2016-12-349 | 10 | DIBBS |
| 4730-01-003-8860 | 2016-12-349 | 62 | DIBBS |
| 4730-01-003-8860 | 2016-12-347 | 10 | DIBBS |
| 4730-01-003-8860 | 2016-08-234 | 33 | DIBBS |
| 4730-01-003-8860 | 2015-08-214 | 52 | DIBBS |
| 4730-01-003-8860 | 2015-01-15 | 152 | DIBBS |
| 4730-01-003-8860 | 2014-08-241 | 41 | DIBBS |
| 4730-01-003-8860 | 2013-01-31 | 22 | DIBBS |
| 4730-01-003-8860 | 2012-10-290 | 12 | DIBBS |
| 4730-01-003-8860 | 2012-03-90 | 9 | DIBBS |
| 4730-01-003-8860 | 2011-11-308 | 11 | DIBBS |
| 4730-01-003-8860 | 2011-04-100 | 16 | DIBBS |
| 4730-01-003-8860 | 2011-02-46 | 5 | DIBBS |
| 4730-01-003-8860 | 2011-01-18 | 7 | DIBBS |
| 4730-01-003-8860 | 2010-12-351 | 16 | DIBBS |
| 4730-01-003-8860 | 2010-08-215 | 11 | DIBBS |
| 4730-01-003-8860 | 2010-04-120 | 5 | DIBBS |
| 4730-01-003-8860 | 2010-03-85 | 9 | DIBBS |
| 4730-01-003-8860 | 2009-08-229 | 5 | United States |
| 4730-01-003-8860 | 2009-07-211 | 5 | DIBBS |
| 4730-01-003-8860 | 2009-06-167 | 6 | United States |
| 4730-01-003-8860 | 2009-05-150 | 6 | DIBBS |
| 4730-01-003-8860 | 2009-01-02 | 9 | DIBBS |
Cross Reference | NSN 4730-01-003-8860
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 12J71-64AE | 24984 | HYDRAFLOW |
| 12J71-64AE | 65506 | FEDERAL INDUSTRIES, INC. |
| 7D0256 | 88277 | BOEING COMPANY, THE DBA BOEING |
| 7D0256-1 | 88277 | BOEING COMPANY, THE DBA BOEING |
| W701 | 79326 | TRANSDIGM INC DBA ADEL WIGGINS GROUP- MILITARY |
| W701-64DE | 79326 | TRANSDIGM INC DBA ADEL WIGGINS GROUP- MILITARY |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4730-01-003-8860
Related Products | NSN 4730-01-003-8860
Technical Data | NSN 4730-01-003-8860
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY, QQ-A-225/6, ALLOY 2024, T6 |
| STYLE DESIGNATOR | U3 FLEXIBLE COUPLING ASSEMBLY |
| OVERALL LENGTH | 1.602 INCHES NOMINAL |
| OUTSIDE DIAMETER | 4.900 INCHES NOMINAL |
| TUBE OUTSIDE DIAMETER FOR WHICH DESIGNED | 4.000 INCHES NOMINAL |
| WORKING PRESSURE AND SERVICE TYPE | 125.0 POUNDS PER SQUARE INCH NOMINAL AIR 125.0 POUNDS PER SQUARE INCH NOMINAL OIL |
| WORKING TEMP AND SERVICE TYPE | 65.0 DEG FAHRENHEIT MINIMUM AIR AND 400.0 DEG FAHRENHEIT MAXIMUM AIR 65.0 DEG FAHRENHEIT MINIMUM OIL AND 400.0 DEG FAHRENHEIT MAXIMUM OIL |
| III END ITEM IDENTIFICATION | C17A AIRCRAFT |
