Product Details | PIPE COUPLING
4730-01-169-0590 A straight fitting 12 inches (304 mm) long or under having the same or different type pipe connection of the same size on both ends. It is designed to join a pipe or pipe fitting to another pipe or pipe fitting. Excludes fittings with threaded external connections on both ends. See also NIPPLE, PIPE.
Part Alternates: A892AABS, A892A-ABS, ABS 5742, ABS5742, LP322, L-P-322, 2892ABS, 2892-ABS, 5803, 58032IN, 5803-2IN, 5803-2IN., 92892, 4730-01-169-0590, 01-169-0590, 4730011690590, 011690590
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 30 DEC 1983 | 01-169-0590 | 06076 ( COUPLING, PIPE ) |
Drawings & Photos | NSN 4730-01-169-0590
Demand History | NSN 4730-01-169-0590
Cross Reference | NSN 4730-01-169-0590
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 2892-ABS | 14889 | GEORGE FISCHER SLOANE INC. |
| 5803 | 12168 | NORTHERN INDIANA BUSINESS SERVICES |
| 5803-2IN | 14007 | NIBCO INC |
| 5803-2IN | 61623 | NIBCO INC CHEMTROL DIV |
| 5803-2IN. | 12168 | NORTHERN INDIANA BUSINESS SERVICES |
| 92892 | 14889 | GEORGE FISCHER SLOANE INC. |
| A892A-ABS | 07861 | TYLER PIPE INDUSTRIES INC |
| ABS 5742 | 19243 | ITT FLUID TECHNOLOGY CORP ITT ENGINEERED VALVES DIV |
| L-P-322 | 81348 | FEDERAL SPECIFICATIONS PROMULGATED BY GENERAL SERVICES |
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
NSNs for Compare ( up to 4 ): Add 4730-01-169-0590
Related Products | NSN 4730-01-169-0590
4730-01-169-0591, 4730-01-169-0592, 4730-01-169-0593, 4730-01-169-0597, 4730-01-169-0626
Technical Data | NSN 4730-01-169-0590
| Characteristic | Specifications |
|---|---|
| MATERIAL | PLASTIC ABS OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | ASTM-D2661,CL-4-2-2 ASSN STD SINGLE MATERIAL RESPONSE OVERALL |
| STYLE DESIGNATOR | A1 PLAIN |
| CONNECTION TYPE | THREADED INTERNAL PIPE 1ST END UNTHREADED INTERNAL PIPE 2ND END |
| CONNECTION STYLE | B14A PLAIN 1ST END B30B SOCKET 2ND END |
| NOMINAL PIPE SIZE ACCOMMODATED | 2.000 INCHES 2ND END |
| THREAD SERIES DESIGNATOR | NPT 1ST END |
| NOMINAL THREAD SIZE | 2.000 INCHES 1ST END |
| NOMINAL OVERALL LENGTH | 2.531 INCHES |
| SPECIAL FEATURES | BLACK MATERIAL |
| SPECIFICATION/STANDARD DATA | 81348-L-P-322B GOVERNMENT SPECIFICATION |
| NONDEFINITIVE SPEC/STD DATA | 2 IN. BY 2 IN. SIZE |
Restrictions/Controls & Freight Information | NSN 4730-01-169-0590
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 052190 | PIPE,TUBING,OR PIPE OR TUBING FITTI |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
