NSN 4730-01-621-5071 AS5174W0504 , 01-621-5071, 016215071
Product Details | BOSS REDUCER
4730-01-621-5071 A straight fitting having a boss connection of a different size at each end. Both connections have external or internal machine threads (straight threads other than pipe or hose series) and are designed to facilitate a gasket, preformed packing, washer, or the like to form a seal at the boss. Excludes BUSHING (as modified).
Part Alternates: AS5174W0504 , 4730-01-621-5071, 01-621-5071, 4730016215071, 016215071
Pipe, Tubing, Hose, and Fittings | Hose, Pipe, Tube, Lubrication, and Railing Fittings
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 47 | 2013253 | 01-621-5071 | 23541 ( REDUCER, BOSS ) |
Drawings & Photos | NSN 4730-01-621-5071
Demand History | NSN 4730-01-621-5071
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| AS5174W0504 | 2019-05-136 | 233 | DIBBS |
| AS5174W0504 | 2019-05-125 | 1 | DIBBS |
| AS5174W0504 | 2019-04-108 | 1 | DIBBS |
| AS5174W0504 | 2011-05-129 | 20 | US |
Cross Reference | NSN 4730-01-621-5071
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| AS5174W0504 | 81343 | SOCIETY OF AUTOMOTIVE ENGINEERS INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4730-01-621-5071
Technical Data | NSN 4730-01-621-5071
| Characteristic | Specifications |
|---|---|
| MATERIAL | ALUMINUM ALLOY 7075 BODY |
| SURFACE TREATMENT | CADMIUM BODY |
| NOMINAL LENGTH | 1.359 INCHES ALL ENDS |
| NOMINAL WIDTH | 0.740 INCHES ALL ENDS |
| THREAD SERIES DESIGNATOR | UNJF ALL ENDS |
| NOMINAL THREAD SIZE | 0.5000 INCHES ALL ENDS |
| THREAD CLASS | 3A ALL ENDS |
| PART NAME ASSIGNED BY CONTROLLING AGENCY | FITTING, UNION AND REDUCER, FLARED |
Restrictions/Controls & Freight Information | NSN 4730-01-621-5071
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Automatic Data Processing Equipment: | 0 | Represents items with no ADP components. NOTE: Codes 1 through 6 are only to be used when the item is Automatic Data Processing Equipment (ADPE) in its entirety and is limited to the type meeting only one of the definitions for codes 1 through 6. (See code 9) |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
