NSN 4820-00-495-6213 DS20754APC29WS14, DS2075-4APC29WS1-4, DS20755APC37WS14
Product Details | GATE VALVE
4820-00-495-6213 A valve having a flat or tapered disk (gate) which moves transversely to the axis of flow by rotating or sliding movements of the stem to open or close the orifice. It may also contain an oval or rectangular shaped slide which may be manually, motor, or pressure operated through the means of an arm or arm assembly. The body flange may be designed to accommodate tube type connectors. It may or may not contain thermal relief features. Includes valve (gate) specifically designed for the control of fluid systems in aircraft or missiles.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: DS20754APC29WS14, DS2075-4APC29WS1-4, DS20755APC37WS14, DS2075-5APC37WS1-4, X155001495300ALTAPC8, X1-5500-1495300ALTAPC8, XT35814ALTAPC8, 1385714, 13857141, 1385714-1, 32556288, 3255628-8, 37WS14, 37WS1-4, 5065522PCV30, 5065-522PCV30, 5224805722451PCV30, 522-4805-722451PCV30, 8031385714, 803-1385714, 80313857141, 803-1385714-1, 803138571412, 803-1385714-12, 80313857141XAF, 803-1385714-1XAF, 8101385714, 810-1385714, 810138571414, 810-1385714-1-4, 810138571414I, 810-13857141-4I, 8101385714REVI, 810-1385714REVI , 8105385714, 810-5385714, 4820-00-495-6213, 00-495-6213, 4820004956213, 004956213
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 12 FEB 1971 | 00-495-6213 | 05482 ( VALVE, GATE ) |
Drawings & Photos | NSN 4820-00-495-6213
Demand History | NSN 4820-00-495-6213
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 8031385714 | 2025-05-150 | 2 | US |
| 8031385714 | 2025-04-114 | 1 | United States |
| 8031385714 | 2025-04-107 | 1 | United States |
| 4820-00-495-6213 | 2018-10-298 | 45 | DIBBS |
| 4820-00-495-6213 | 2018-06-171 | 8 | US |
| 32556288 | 2015-07-193 | 20 | United States |
| 4820-00-495-6213 | 2013-11-319 | 6 | US |
| 4820-00-495-6213 | 2013-01-14 | 4 | Taiwan |
| 8031385714 | 2010-09-257 | 1 | US |
| 4820-00-495-6213 | 2010-03-67 | 1 | US |
Cross Reference | NSN 4820-00-495-6213
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 1385714 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 1385714-1 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 3255628-8 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 37WS1-4 | 63686 | THE WALWORTH COMPANY |
| 5065-522PCV30 | 81316 | PORTSMOUTH NAVAL SHIPYARD |
| 522-4805-722451PCV30 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 522-4805-722451PCV30 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 803-1385714 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 803-1385714-1 | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 803-1385714-1 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 803-1385714-12 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 803-1385714-1XAF | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 810-1385714 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| 810-1385714-1-4 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 810-13857141-4I | 03950 | NAVAL INVENTORY CONTROL POINT MECHANICSBURG |
| 810-1385714REVI | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| 810-5385714 | 53711 | NAVAL SEA SYSTEMS COMMAND |
| DS2075-4APC29WS1-4 | 63686 | THE WALWORTH COMPANY |
| DS2075-5APC37WS1-4 | 63686 | THE WALWORTH COMPANY |
| X1-5500-1495300ALTAPC8 | 80064 | NAVAL SHIP SYSTEMS COMMAND |
| XT35814ALTAPC8 | 01359 | FAIRCHILD CONTROLS CORPORATION |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4820-00-495-6213
Technical Data | NSN 4820-00-495-6213
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY 922 BODY STEEL COMP 416 SEAT COPPER ALLOY STEM COPPER ALLOY DISK |
| MATERIAL DOCUMENT AND CLASSIFICATION | ASTM B61 ASSN STD SINGLE MATERIAL RESPONSE BODY ASTM A582-416 ASSN STD SINGLE MATERIAL RESPONSE SEAT ASTM B198 AL875 ASSN STD SINGLE MATERIAL RESPONSE AND ASTM B371 AL697 ASSN STD SINGLE MATERIAL RESPONSE STEM ASTM B149-11B MOD. ASSN STD SINGLE MATERIAL RESPONSE DISK |
| VALVE SIZE | 0.250 INCHES |
| PRESSURE CLASS | 200.0 POUNDS PER SQUARE INCH |
| MAXIMUM OPERATING PRESSURE AND MEDIA FOR WHICH DESIGNED | 200.0 POUNDS PER SQUARE INCH WATER-OIL-GAS AND 400.0 POUNDS PER SQUARE INCH STEAM |
| MAXIMUM OPERATING TEMP AND MEDIA FOR WHICH DESIGNED | 550.0 DEG FAHRENHEIT WATER-OIL-GAS AND 150.0 DEG FAHRENHEIT STEAM |
| VALVE OPERATION METHOD | MANUAL |
| INLET RELATIONSHIP WITH OUTLET | IDENTICAL |
| CONNECTION TYPE | SOCKET, WELD, PIPE |
| NOMINAL PIPE SIZE ACCOMMODATED | 0.250 INCHES |
| STEM TYPE | RISING |
| BONNET TYPE | INSIDE SCREW |
| BONNET ATTACHMENT METHOD | UNION |
| FEATURES PROVIDED | BONNET PACKING |
| SPECIAL FEATURES | INTEGRAL SEAT |
Restrictions/Controls & Freight Information | NSN 4820-00-495-6213
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 576 | unknown |
| Originating Activity Code | AX | Defense Supply Center Columbus Columbus, OH 43216-5000 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4820-00-495-6213
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 3B | Navy-owned stocks of field level repairable DLA material Naval Inventory Control Point, Mechanicsburg |
| Special Material ID | L2 | Hydrostatic Testing Commodity Contracts |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Y | TERMINAL ITEM #(NON-STOCKED ITEMS) Future procurement is not authorized. No wholesale stock is available for issue. 1. Requisitions will not be processed to the wholesale manager. 2. Internal Service/agency requisitioning may be continued in accordance with the Service/agency requisitioning policies. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
