Product Details | BUTTERFLY VALVE
4820-00-556-4490 A valve that controls flow by a circular disk, or a pair of semicircular disks, attached to a common spindle or lever turning on a diametral axis.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 32181211, 321812-1-1, 32181221, 321812-2-1, 4820-00-556-4490, 00-556-4490, 4820005564490, 005564490
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 04 NOV 1974 | 00-556-4490 | 05489 ( VALVE, BUTTERFLY ) |
Drawings & Photos | NSN 4820-00-556-4490
Request a Quote
Comments | What our customers are saying...
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Related Products | NSN 4820-00-556-4490
4820-00-556-4976, 4820-00-556-5088, 4820-00-556-7198, 4820-00-556-9812, 4820-00-556-9859
Technical Data | NSN 4820-00-556-4490
| Characteristic | Specifications |
|---|---|
| MATERIAL | STEEL BODY STEEL BODY LINING STEEL FLOW CONTROL DEVICE STEEL SEAT STEEL STEM |
| SURFACE TREATMENT | CADMIUM |
| STYLE DESIGNATOR | A1 STRAIGHT THRU |
| FACE TO FACE DISTANCE | 4.437 INCHES |
| VALVE OPERATION METHOD | MANUAL |
| CONNECTION TYPE | FLANGE 1ST END |
| FLANGE SHAPE | ROUND 1ST END |
| NOMINAL OUTSIDE DIAMETER | 5.125 INCHES 1ST END |
| NOMINAL THICKNESS | 0.156 INCHES 1ST END |
| FLANGE FACE DESIGN | PLAIN 1ST END |
| MOUNTING FACILITY | LUG |
| TEST DATA DOCUMENT | 99193-321821-1-1 DRAWING |
Restrictions/Controls & Freight Information | NSN 4820-00-556-4490
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
