NSN 4820-00-640-6553 4581, 458-1, 00-640-6553
Product Details | GATE VALVE
4820-00-640-6553 A valve having a flat or tapered disk (gate) which moves transversely to the axis of flow by rotating or sliding movements of the stem to open or close the orifice. It may also contain an oval or rectangular shaped slide which may be manually, motor, or pressure operated through the means of an arm or arm assembly. The body flange may be designed to accommodate tube type connectors. It may or may not contain thermal relief features. Includes valve (gate) specifically designed for the control of fluid systems in aircraft or missiles.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 4581, 458-1, 4820-00-640-6553, 00-640-6553, 4820006406553, 006406553
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 01 JAN 1963 | 00-640-6553 | 05482 ( VALVE, GATE ) |
Drawings & Photos | NSN 4820-00-640-6553
Demand History | NSN 4820-00-640-6553
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 4581 | 2016-10-280 | 1 | United States |
| 4820-00-640-6553 | 2009-04-103 | 1 | US |
Cross Reference | NSN 4820-00-640-6553
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| 458-1 | 14956 | PICHEL INDUSTRIES INC |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 4820-00-640-6553
Technical Data | NSN 4820-00-640-6553
| Characteristic | Specifications |
|---|---|
| MATERIAL | COPPER ALLOY BODY COPPER ALLOY SEAT COPPER ALLOY STEM COPPER ALLOY DISK |
| MAXIMUM OPERATING PRESSURE AND MEDIA FOR WHICH DESIGNED | 200.0 POUNDS PER SQUARE INCH STEAM AND 400.0 POUNDS PER SQUARE INCH WATER-OIL-GAS |
| VALVE OPERATION METHOD | MANUAL |
| CONNECTION TYPE | THREADED INTERNAL PIPE |
| THREAD SERIES DESIGNATOR | NPT |
| NOMINAL THREAD SIZE | 0.750 INCHES |
| STEM TYPE | NONRISING |
| BONNET TYPE | INSIDE SPRING |
| BONNET ATTACHMENT METHOD | THREADED |
| FEATURES PROVIDED | BONNET PACKING |
| SPECIAL FEATURES | 0.750 IN. PIPE SIZE;R.H. THD;14 THDS PER INCH;MAX OPERATING TEMP 500 DEG F |
Restrictions/Controls & Freight Information | NSN 4820-00-640-6553
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
