NSN 4820-01-197-2882 12428, 01-197-2882, 011972882
Product Details | VALVE SEAT
4820-01-197-2882 A replaceable item designed to provide a stationary seating surface for a mating, moveable item such as a valve disk or the like. The body may have a flange of various shapes. For diesel and gasoline reciprocating engines, see INSERT, ENGINE VALVE SEAT.20248100015Valves, Powered48200018Valves, Nonpowered
Part Alternates: 12428, 4820-01-197-2882, 01-197-2882, 4820011972882, 011972882
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 48 | 19 DEC 1984 | 01-197-2882 | 22113 ( SEAT, VALVE ) |
Drawings & Photos | NSN 4820-01-197-2882
Demand History | NSN 4820-01-197-2882
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 12428 | 2025-11-329 | 5 | DIBBS |
| 12428 | 2025-10-294 | 9 | DIBBS |
| 12428 | 2025-09-260 | 4 | DIBBS |
| 12428 | 2024-12-347 | 13 | DIBBS |
| 4820-01-197-2882 | 2016-01-10 | 11 | DIBBS |
| 4820-01-197-2882 | 2015-12-351 | 23 | DIBBS |
| 4820-01-197-2882 | 2015-07-186 | 6 | DIBBS |
| 4820-01-197-2882 | 2015-06-159 | 9 | DIBBS |
| 4820-01-197-2882 | 2015-05-148 | 9 | DIBBS |
| 4820-01-197-2882 | 2014-12-353 | 2 | DIBBS |
| 4820-01-197-2882 | 2014-12-342 | 2 | DIBBS |
| 4820-01-197-2882 | 2014-11-310 | 4 | DIBBS |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 4820-01-197-2882
Related Products | NSN 4820-01-197-2882
Technical Data | NSN 4820-01-197-2882
| Characteristic | Specifications |
|---|---|
| STYLE DESIGNATOR | B10 PLAIN FLANGED |
| FLANGE DIAMETER | 0.332 INCHES MINIMUM AND 0.336 INCHES MAXIMUM |
| BODY OUTSIDE DIAMETER | 0.337 INCHES MINIMUM AND 0.347 INCHES MAXIMUM |
| BODY INSIDE DIAMETER | 0.275 INCHES MINIMUM AND 0.285 INCHES MAXIMUM |
| FLANGE SEAT TO DISK END HEIGHT | 0.235 INCHES NOMINAL |
| UNDER FLANGE HEIGHT | 0.265 INCHES NOMINAL |
| MATERIAL | STEEL COMP 17-4PH OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | AMS 5643 ASSN STD ALL MATERIAL RESPONSES OVERALL |
| SURFACE TREATMENT | RUBBER OVERALL |
| III END ITEM IDENTIFICATION | MODEL 2276,PUMP HYDRAULIC |
Restrictions/Controls & Freight Information | NSN 4820-01-197-2882
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 051080 | FAUCETS,BIBCOCKS,GATES VALVES |
| Less than car load rating | ||
| Less than truck load rating | W | Rating Variable |
| Water commodity Code | 594 | unknown |
| Originating Activity Code | ZA | Australia ZB ZC |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | V | Vehicles, machinery, shop and warehouse equipment and supplies, including special tools and equipment, ground servicing and special purpose vehicles, marine equipment and supplies, repair and maintenance parts for the above. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
Management | NSN 4820-01-197-2882
Navy| Category | Code | Description |
|---|---|---|
| Cognizance Codes | 9B | Navy-owned stocks of DLA material Naval Inventory Control Point, Mechanicsburg |
| Source of Supply | SMS | Defense Logistics Agency Enterprise Business Systems |
| Agency | DN | Department of the Navy |
| Service Organization | N | U.S. Navy |
| Acquisition Advice Codes | Z | INSURANCE/NUMERIC STOCKAGE OBJECTIVE ITEM # Items which may be required occasionally or intermittently, and prudence requires that a nominal quantity of materiel be stocked due to the essentiality or the lead time of the item. 1. The item is centrally managed, stocked, and issued. 2. Requisitions will be submitted in accordance with IMM/Service requisitioning procedures. |
| Controlled Item Code | U | UNCLASSIFIED |
| Shelf Life Code | 0 | Nondeteriorative |
| Purchasing | QTY UOM |
1 EA : Each |
