NSN 5120-01-133-0563 10273984, 01-133-0563, 011330563
Product Details | FOLDING HANDLE
5120-01-133-0563
Part Alternates: 10273984, 5120-01-133-0563, 01-133-0563, 5120011330563, 011330563
Hand Tools | Hand Tools, Nonedged, Nonpowered
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 51 | 09 JUN 1982 | 01-133-0563 | 77777 ( ) |
Drawings & Photos | NSN 5120-01-133-0563
Demand History | NSN 5120-01-133-0563
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 10273984 | 2024-11-313 | 12 | Italy |
| 5120-01-133-0563 | 2017-02-59 | 15 | Italy |
| 5120-01-133-0563 | 2017-02-47 | 15 | United States |
| 5120-01-133-0563 | 2015-08-237 | 4 | United States |
| 10273984 | 2014-10-301 | 25 | TR |
| 5120-01-133-0563 | 2014-10-300 | 4 | United States |
| 5120-01-133-0563 | 2014-03-71 | 1 | US |
| 10273984 | 2014-02-56 | 2 | United States |
| 5120-01-133-0563 | 2014-02-35 | 6 | United States |
| 10273984 | 2012-06-180 | 7 | United States |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
Ernie G.
Honeywell
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
NSNs for Compare ( up to 4 ): Add 5120-01-133-0563
Related Products | NSN 5120-01-133-0563
Technical Data | NSN 5120-01-133-0563
| Characteristic | Specifications |
|---|---|
| GENERAL CHARACTERISTICS ITEM DESCRIPTION | CONSIST OF 1 PLATE ALUMINUM ALLOYTYPE 6061-T6 PER QQ-A-250; THE PLATE FINISH IS BLACK ANODIZE PER MIL-A-8625;1 BAIL AND SPRING CORROSION RESISTANT STEEL TYPE 302 OR 304 PER QQ-S763; FINISH FOR BAIL AND SPRING IS BLACK OXIDEPER MIL-C-13924; LOAD CARRYING CAPACITY IS 150 POUNDS MINIMUM WITHOUT PERMANENT DAMAGE TO THE PLATE; PLATE CONSISTOF 6 HOLES |
| TEST DATA DOCUMENT | 18876-10273984 DRAWING |
| III END ITEM IDENTIFICATION | 1430-01-240-0640 |
| MANUFACTURERS CODE | 18876 |
| DESIGN CONTROL REFERENCE | 10273984 |
Restrictions/Controls & Freight Information | NSN 5120-01-133-0563
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Precious Metals Indicator Code: | A | Item does not contain precious metal |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| NMF Description | 095142 | HARDWARE HANDLES,IRON/STEEL |
| Less than car load rating | Q | 70 |
| Less than truck load rating | Q | 70.0 |
| Water commodity Code | 713 | unknown |
| Originating Activity Code | BD | U.S. Army Aviation and Missile Command Redstone Arsenal, AL 35898-5230 |
| Air Dimension Code | A | Shipment is not a consolidation and does not exceed 72 inches in any dimension. |
| Air Commodity | B | Construction materials: Includes paint and related materials, prefabricated building, wood products, metal and composition materials and their products, commercial hardware and miscellaneous items, cement, asphalt, building maintenance materials. |
| Air Special Handling | Z | No special handling required. |
| Special Handling Code | 9 | unknonwn |
| HAZMAT | ||
| Type of Cargo | Z | No special type of cargo code applicable |
