NSN 5305-01-064-5449 NAS1189E08P10, NAS1189E08P10L, NAS1189E08P10NK
Product Details | SOCKET HEAD CAP SCREW
5305-01-064-5449 An externally threaded fastener whose threaded portion is of one nominal diameter. The head has an internal socket or multiple spline for use with an inserted driver. A locking feature may be incorporated in the design of the head or threads. Excludes items with bevel (conical) heads. See BOLT, INTERNAL WRENCHING. Excludes SCREW, SHOULDER; and SCREW, MACHINE.
Part Alternates: NAS1189E08P10, NAS1189E08P10L, NAS1189E08P10NK, 5305-01-064-5449, 01-064-5449, 5305010645449, 010645449
Hardware and Abrasives | Screws
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 01-064-5449 | 16282 ( SCREW, CAP, SOCKET HEAD ) |
Drawings & Photos | NSN 5305-01-064-5449
Cross Reference | NSN 5305-01-064-5449
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| NAS1189E08P10 | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| NAS1189E08P10HNK | 04348 | LAWRENCE ENGINEERING AND SUPPLY INC |
| NAS1189E08P10HNK | 07679 | HARDWARE SPECIALTY CO. INC. |
| NAS1189E08P10HNK | 07851 | NOR-CAL SUPPLY CO.INC. |
| NAS1189E08P10HNK | 08938 | AIR INDUSTRIES CO INC |
| NAS1189E08P10HNK | 16941 | LONG-LOK FASTENERS CORPORATION |
| NAS1189E08P10HNK | 17446 | HUCK INTERNATIONAL, INC. DBA ALCOA FASTENING SYSTEMS |
| NAS1189E08P10HNK | 50568 | APCOM INC |
| NAS1189E08P10HNK | 53606 | PLASTIC AND METAL PRODUCTS CORPORATION |
| NAS1189E08P10HNK | 56357 | ND INDUSTRIES, INC. DIV EASTERN DIVISION |
| NAS1189E08P10HNK | 56878 | SPS TECHNOLOGIES, LLC DBA AEROSPACE DIVISION |
| NAS1189E08P10HNK | 58998 | EMHART TEKNOLOGIES LLC DBA FASTENER INNOVATION TECHNOLOGY |
| NAS1189E08P10HNK | 73197 | HI-SHEAR CORPORATION |
| NAS1189E08P10HNK | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
| NAS1189E08P10HNK | 80539 | SPS TECHNOLOGIES, LLC DBA AEROSPACE FASTENERS GROUP |
| NAS1189E08P10HNK | 92215 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| NAS1189E08P10HNK | 97928 | HUCK INTL INC |
| NAS1189E08P10HNK | L4528 | LISI AEROSPACE CANADA CORP |
| NAS1189E08P10L | 06950 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| NAS1189E08P10L | 53606 | PLASTIC AND METAL PRODUCTS CORPORATION |
| NAS1189E08P10L | 56878 | SPS TECHNOLOGIES, LLC DBA AEROSPACE DIVISION |
| NAS1189E08P10L | 80539 | SPS TECHNOLOGIES, LLC DBA AEROSPACE FASTENERS GROUP |
| NAS1189E08P10L | 92215 | ALCOA GLOBAL FASTENERS, INC. DBA ALCOA FASTENING SYSTEMS |
| NAS1189E08P10NK | 04348 | LAWRENCE ENGINEERING AND SUPPLY INC |
| NAS1189E08P10NK | 07679 | HARDWARE SPECIALTY CO. INC. |
| NAS1189E08P10NK | 07851 | NOR-CAL SUPPLY CO.INC. |
| NAS1189E08P10NK | 08938 | AIR INDUSTRIES CO INC |
| NAS1189E08P10NK | 16941 | LONG-LOK FASTENERS CORPORATION |
| NAS1189E08P10NK | 17446 | HUCK INTERNATIONAL, INC. DBA ALCOA FASTENING SYSTEMS |
| NAS1189E08P10NK | 50568 | APCOM INC |
| NAS1189E08P10NK | 56357 | ND INDUSTRIES, INC. DIV EASTERN DIVISION |
| NAS1189E08P10NK | 58998 | EMHART TEKNOLOGIES LLC DBA FASTENER INNOVATION TECHNOLOGY |
| NAS1189E08P10NK | 73197 | HI-SHEAR CORPORATION |
| NAS1189E08P10NK | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5305-01-064-5449
Technical Data | NSN 5305-01-064-5449
| Characteristic | Specifications |
|---|---|
| THREAD SERIES DESIGNATOR | UNJC |
| NOMINAL THREAD DIAMETER | 0.164 INCHES |
| THREAD QUANTITY PER INCH | 32 |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| THREAD LENGTH | 0.464 INCHES MINIMUM AND 0.557 INCHES MAXIMUM |
| FASTENER LENGTH | 0.594 INCHES MINIMUM AND 0.625 INCHES MAXIMUM |
| MATERIAL | IRON ALLOY 660 OVERALL |
| SURFACE TREATMENT | PASSIVATE OVERALL |
| HEAD STYLE | C50 FLAT COUNTERSUNK |
| HEAD DIAMETER | 0.270 INCHES MINIMUM AND 0.332 INCHES MAXIMUM |
| COUNTERSINK ANGLE | 100.0 DEGREES NOMINAL |
| INTERNAL DRIVE STYLE | D1 CROSS RECESS TYPE 1 |
| LOCKING FEATURE | PELLET THREADS |
| SURFACE FINISH | 32.0 MICROINCHES BEARING SURFACE OF HEAD 32.0 MICROINCHES THREADS |
| SPECIFICATION/STANDARD DATA | 80205-NAS1189 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
Restrictions/Controls & Freight Information | NSN 5305-01-064-5449
| Category | Code | Description |
|---|---|---|
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
