NSN 5305-01-493-7120 NAS18010630, NAS1801-06-30, 01-493-7120
Product Details | MACHINE SCREW
5305-01-493-7120 An externally threaded fastener whose threaded portion is of one nominal diameter, No 0 (0.060 in./1.5 mm) or larger, designed to be held or driven with either a wrench or an inserted driver or both (excluding internal socket or internal multiple spline types), in sizes below No. 10 (0.190 in./5 mm). No. 10 and larger sizes must have a head designed for any type inserted driver (excluding internal socket or internal multiple spline types), but may also be designed for external wrenching. A locking feature may be incorporated in the design of the head or threads. Excludes BOLT, CLEVIS; BOLT, EXTERNALLY RELIEVED BODY; SCREW, EXTERNALLY RELIEVED BODY; and SCREW, ASSEMBLED WASHER. See also, SCREW, INSTRUMENT; BOLT, MACHINE; BOLT, INTERNAL WRENCHING; and SCREW, CAP SOCKET HEAD.
Part Alternates: NAS18010630, NAS1801-06-30, 5305-01-493-7120, 01-493-7120, 5305014937120, 014937120
Hardware and Abrasives | Screws
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 15 JAN 2002 | 01-493-7120 | 06657 ( SCREW, MACHINE ) |
Drawings & Photos | NSN 5305-01-493-7120
Demand History | NSN 5305-01-493-7120
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| NAS18010630 | 2024-12-339 | 188 | US |
| 5305-01-493-7120 | 2023-01-06 | 20 | US |
| 5305-01-493-7120 | 2023-01-06 | 40 | US |
| 5305-01-493-7120 | 2023-01-06 | 20 | United States |
| 5305-01-493-7120 | 2023-01-06 | 40 | United States |
| NAS18010630 | 2013-05-129 | 200 | Czech Republic |
| NAS18010630 | 2013-04-94 | 150 | Czech Republic |
| NAS18010630 | 2013-04-94 | 150 | Czech Republic |
| NAS18010630 | 2013-03-67 | 150 | Czech Republic |
| NAS18010630 | 2013-02-35 | 150 | Czech Republic |
| NAS18010630 | 2013-01-07 | 100 | Czech Republic |
| NAS18010630 | 2013-01-03 | 100 | Czech Republic |
| NAS18010630 | 2012-11-331 | 50 | Czech Republic |
| NAS18010630 | 2012-10-284 | 50 | Czech Republic |
| NAS18010630 | 2012-07-206 | 80 | Czech Republic |
| NAS18010630 | 2012-05-137 | 80 | Czech Republic |
