NSN 5306-00-054-8351 GS1221M156, GS1221M15-6 , 02

Product Details | U BOLT


5306-00-054-8351 An externally threaded fastener bent approximately 180 degrees (3.141 radians) in the shape of the letter U and with both ends threaded.

Part Alternates: GS1221M156, GS1221M15-6 , 02, 20ME125, 5306-00-054-8351, 00-054-8351, 5306000548351, 000548351

Hardware and Abrasives | Bolts

Supply Group (FSG) NSN Assign. NIIN
53 15 OCT 1972 00-054-8351

Drawings & Photos | NSN 5306-00-054-8351



Demand History | NSN 5306-00-054-8351


Part Number Request Date QTY Origin
02 2019-01-03 10
5306-00-054-8351 2013-05-13 500 DIBBS
5306-00-054-8351 2013-04-10 477 DIBBS
5306-00-054-8351 2013-04-10 20 DIBBS
20ME125 2007-09-25 2 United States

Cross Reference | NSN 5306-00-054-8351


Part Number Cage Code Manufacturer
02 71747 CHICAGO HARDWARE AND FIXTURE COMPANY

Request a Quote



Comments | What our customers are saying...


Honeywell

Thank you very much for the excellent service and professional customer care.

Ernie G. Honeywell
Raytheon

The service was excellent. I can think of no improvements to date that you can make regarding internet sales.

John L. Raytheon
General Dynamics

The representative for WBParts was efficient & handled our request in a timely & professional manner.

Karen G. General Dynamics
US Airforce

Tried two other sources, neither of them responded, was all done online, never spoke to anyone.

Rex S. US Airforce
NASA

The response is quick and the price is often very good. We are completely satisfied.


NSNs for Compare ( up to 4 ): Add 5306-00-054-8351


Technical Data | NSN 5306-00-054-8351


Characteristic Specifications
THREAD SERIES DESIGNATOR UNC
NOMINAL THREAD DIAMETER 0.250 INCHES
THREAD QUANTITY PER INCH 20
THREAD CLASS 3A
THREAD DIRECTION RIGHT-HAND
THREAD LENGTH 0.625 INCHES MINIMUM
MATERIAL STEEL OVERALL
SURFACE TREATMENT ZINC OVERALL
STYLE DESIGNATOR B30 ROUND BEND
DISTANCE FROM INSIDE CENTER OF BEND TO BOLT END 1.250 INCHES NOMINAL
INSIDE DISTANCE BETWEEN SHANKS 0.750 INCHES NOMINAL
SPECIAL FEATURES FURNISH WITH 2 HEXAGON NUTS
