NSN 5306-01-049-0639 NAS620515D, NAS6205-15D, 142C846H01
Product Details | SHEAR BOLT
5306-01-049-0639 A high strength, 160,000 pounds per square inch (1100 megapascals) minimum tensile strength externally threaded fastener designed for use in applications involving great shear stress. The head is designed to accommodate an external wrench or driver. The head is not designed to be held or driven with an inserted driver, nor is it designed for rotation by the thumb and fingers. The unthreaded portion is of specific grip length, plated or unplated, and is machined to a tolerance of one thousandth (0.001) of an inch (0.025 mm) or less of a specific diameter for items one inch (25 mm) or less in diameter. Items over one inch (25 mm) in diameter shall have a tolerance of fifteen ten thousandths (0.0015) of an inch (0.038 mm) or less. The nominal major diameter of the threads shall be at least one thousandth (0.001) of an inch (0.025 mm) below the minimum shank diameter, but not below the minimum major diameter for applicable class of fit, as shown in the Screw Thread Standards, FED STD H28 and/or other nationally recognized standards. A locking feature may be incorporated in the design of the head or threads. See BOLT, MACHINE and BOLT, CLEVIS.
Part Alternates: NAS620515D, NAS6205-15D, 142C846H01 , 32D901F450DF2A, 5306-01-049-0639, 01-049-0639, 5306010490639, 010490639
Hardware and Abrasives | Bolts
| Supply Group (FSG) | NSN Assign. | NIIN | Item Name Code (INC) |
|---|---|---|---|
| 53 | 10 OCT 1977 | 01-049-0639 | 15903 ( BOLT, SHEAR ) |
Drawings & Photos | NSN 5306-01-049-0639
Demand History | NSN 5306-01-049-0639
| Part Number | Request Date | QTY | Origin |
|---|---|---|---|
| 5306-01-049-0639 | 2025-09-247 | 1 | United States |
| 5306-01-049-0639 | 2025-08-233 | 1 | US |
| 5306-01-049-0639 | 2025-02-55 | 30 | US |
| 5306-01-049-0639 | 2021-01-08 | 1 | DIBBS-RFPs |
| 5306-01-049-0639 | 2019-10-301 | 5296 | DIBBS |
| 5306-01-049-0639 | 2019-10-293 | 5296 | DIBBS |
| 5306-01-049-0639 | 2018-04-95 | 2908 | DIBBS |
| 5306-01-049-0639 | 2018-01-15 | 40 | US |
| 142C846H01 | 2017-07-193 | 5 | US |
| 142C846H01 | 2017-06-179 | 5 | United Kingdom |
| NAS620515D | 2015-12-347 | 5 | HK |
| 5306-01-049-0639 | 2015-07-182 | 3407 | DIBBS |
| 142C846H01 | 2015-04-119 | 20 | United States |
| 142C846H01 | 2011-02-54 | 20 | United States |
| 5306-01-049-0639 | 2009-04-114 | 3204 | DIBBS |
| 142C846H01 | 2008-08-224 | 100 | US |
| 5306-01-049-0639 | 2008-03-70 | 3204 | DIBBS |
| 32D901F450DF2A | 2008-01-30 | 20 | United Arab Emirates |
| 142C846H01 | 2007-12-344 | 10 | Canada |
| 142C846H01 | 2007-12-343 | 10 | Canada |
| 32D901F450DF2A | 2007-12-339 | 10 | US |
| 32D901F450DF2A | 2007-06-171 | 20 | United Arab Emirates |
| 32D901F450DF2A | 2007-06-165 | 20 | PK |
Cross Reference | NSN 5306-01-049-0639
| Part Number | Cage Code | Manufacturer |
|---|---|---|
| NAS6205-15D | 80205 | NATIONAL AEROSPACE STANDARDS COMMITTEE AEROSPACE INDUSTRIES |
Request a Quote
What Our Customers Say
Thank you very much for the excellent service and professional customer care.
The service was excellent. I can think of no improvements to date that you can make regarding internet sales.
The representative for WBParts was efficient & handled our request in a timely & professional manner.
Tried two other sources, neither of them responded, was all done online, never spoke to anyone.
The response is quick and the price is often very good. We are completely satisfied.
Compare
Related Products | NSN 5306-01-049-0639
Technical Data | NSN 5306-01-049-0639
| Characteristic | Specifications |
|---|---|
| THREAD SERIES DESIGNATOR | UNJF |
| NOMINAL THREAD DIAMETER | 0.312 INCHES |
| THREAD QUANTITY PER INCH | 24 |
| THREAD CLASS | 3A |
| THREAD DIRECTION | RIGHT-HAND |
| THREAD LENGTH | 0.413 INCHES MINIMUM AND 0.463 INCHES MAXIMUM |
| FASTENER LENGTH | 1.361 INCHES MINIMUM AND 1.391 INCHES MAXIMUM |
| MATERIAL | STEEL COMP E4340 OR STEEL COMP 8740 OVERALL |
| MATERIAL DOCUMENT AND CLASSIFICATION | MIL-S-5000 MIL SPEC 1ST MATERIAL RESPONSE OR MIL-S-6049 MIL SPEC 2ND MATERIAL RESPONSE OR AMS 6322 ASSN STD 2ND MATERIAL RESPONSE OVERALL |
| SURFACE TREATMENT | CADMIUM AND CHROMATE OVERALL |
| SURFACE TREATMENT DOCUMENT AND CLASSIFICATION | QQ-P-416 TY 2 CL 2 FED SPEC SINGLE TREATMENT RESPONSE OVERALL |
| HARDNESS RATING | 36.0 ROCKWELL C MINIMUM AND 40.0 ROCKWELL C MAXIMUM OVERALL |
| MINIMUM TENSILE STRENGTH | 160000 POUNDS PER SQUARE INCH |
| HEAD STYLE | C3 DISHED HEXAGON |
| HEAD HEIGHT | 0.156 INCHES MINIMUM AND 0.171 INCHES MAXIMUM |
| WIDTH BETWEEN FLATS | 0.492 INCHES MINIMUM AND 0.502 INCHES MAXIMUM |
| GRIP LENGTH | 0.928 INCHES MINIMUM AND 0.948 INCHES MAXIMUM |
| GRIP DIAMETER | 0.3110 INCHES MINIMUM AND 0.3120 INCHES MAXIMUM |
| SURFACE FINISH | 32.0 MICROINCHES BEARING SURFACE OF HEAD 32.0 MICROINCHES GRIP 32.0 MICROINCHES THREADS |
| DISTANCE FROM HEAD LARGEST BEARING SURFACE TO SHANK HOLE CENTER | 1.169 INCHES MINIMUM AND 1.219 INCHES MAXIMUM FIRST HOLE |
| SHANK UNTHREADED HOLE DIAMETER | 0.076 INCHES MINIMUM AND 0.086 INCHES MAXIMUM FIRST HOLE |
| SPECIFICATION/STANDARD DATA | 80205-NAS6205 PROFESSIONAL/INDUSTRIAL ASSOCIATION STANDARD |
Restrictions/Controls & Freight Information | NSN 5306-01-049-0639
| Category | Code | Description |
|---|---|---|
| Shelf-Life Code: | 0 | Nondeteriorative |
| Hazardous Material Indicator Code | N | There is no data in the HMIS and the NSN is in an FSC not generally suspected of containing hazardous materials |
| Demilitarization Code: | A | Non-Munitions List Item/ Non-Strategic List Item - Demilitarization not required. |
| Controlled Inventory Item Code: | U | UNCLASSIFIED |
| Precious Metals Indicator Code: | U | Precious metal type is unknown |
| Criticality Code: | X | The item does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. |
| Category | Code | Description |
|---|---|---|
| No Freight Information | ||
